Universal Bracket Small Hikvision
Hikvision small universal bracket for CCTV cameras. Ideal for mounting cameras in CCTV and security installations.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Alternatively Known As: Hikvision Small Universal Bracket, Hikvision Vertical Pole Mount, CCTV Camera Pole Bracket
Technical Specifications
- Model: DS-1275ZJ-S-SUS
- Mount Type: Vertical pole mount
- Material: Stainless steel with surface spray treatment
- Colour: White
- Adjustable Pole Diameter: 67–127 mm
- Maximum Load Capacity: 10 kg
- Mounting Interface: 12 x M4 mounting holes
- Outdoor Installation: Waterproof rubber required
- Dimensions (H x L x W): 144mm x 131.6mm x 44.3mm
- Weight: 0.76 kg
Key Features
- Designed for mounting compatible CCTV cameras to vertical poles
- Adjustable clamp accommodates poles from 67 mm to 127 mm diameter
- Stainless steel construction provides a durable mounting structure
- Supports a maximum camera and accessory load of 10 kg
- Suitable for use with selected Hikvision camera and wall-mount accessories
Applications
- CCTV camera pole installations
- Security camera mounting on round poles and columns
- Commercial, industrial and residential surveillance systems
- Outdoor security camera installations when correctly weather-sealed
Environmental Benefits
- Stainless steel is durable and recyclable, supporting extended product service life
- Durable construction can reduce replacement frequency and associated material waste
Warranty Information
Hikvision Australia warranty policy identifies brackets as consumable accessories covered for 12 months from the product shipment date, subject to applicable terms and authorised distribution requirements.
Available Now
Available through Hikvision and authorised Australian security equipment distributors.
