UV LED Optical Sensor | 385 nm Wavelength | IP67 Rated | High Ambient Light Immunity | by SICK
The UV LED Optical Sensor is designed for industrial automation, featuring a 385 nm wavelength light source and an IP67 rated enclosure for dust and water protection. With a sensing distance of up to 100 mm and high ambient light immunity, it's perfect for barcode scanning and object detection in manufacturing lines, ensuring reliable performance in challenging environments.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Sensing distance: ≤ 100 mm with ±10 mm tolerance
- Working range: 90 mm to 110 mm
- Light source: LED, UV at 385 nm wavelength
- Light spot size: 180 mm x 9 mm
- Receiving filters: 420 to 750 nm
- Barcode types supported: 2/5 Interleaved with checksum
- Minimum module width: ≥ 1.5 mm
- Minimum line radius: ≥ 0.5 m
- Track colors detected: Orange, green, yellow
- Safety-related MTTFD: 271 years
- Supply voltage: 18 V DC to 30 V DC
- Power consumption: < 3 W
- Sampling rate: 10 ms
- Switching output: Push-pull PNP/NPN, max 100 mA
- Protection class: III
- Circuit protection: Reverse polarity, short-circuit, interference pulse suppression
- Connection type: Plug, M12, 5-pin
- Operating temperature: -10 °C to +55 °C
- Storage temperature: -25 °C to +75 °C
- Enclosure rating: IP67
- Communication interfaces: IO-Link COM3 (230.4 kBaud), Modbus RTU RS-485
- Cycle time: 5 ms
- Process data length: 21 Byte
- Dimensions (H x L x W): 62mm x 52.5mm x 31mm
- Weight: 0.25 kg
Key Features
- Rectangular zinc diecast housing
- Sensing distance up to 100 mm with ±10 mm tolerance
- LED UV light source with 385 nm wavelength
- High ambient light immunity of 50,000 lx
- IP67 rated enclosure for dust and water protection
- Push-pull PNP/NPN switching output
- IO-Link and Modbus RTU RS-485 communication interfaces
- Short cycle time of 5 ms and 21 Byte process data length
- Reverse polarity and short-circuit protected outputs
- LED risk group 2 compliant with IEC 62471
Professional Installation Requirements
- Installation should be performed by a qualified technician familiar with industrial sensor wiring and configuration, ensuring compliance with electrical safety standards.
Applications
- Industrial automation for barcode scanning
- Object detection in manufacturing lines
- Color track detection in quality control
Standards & Compliance
- AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Low power consumption under 3 W reduces energy usage
- Durable zinc diecast housing extends product lifespan
- IP67 rating ensures protection against environmental contaminants
Warranty Information
Standard manufacturer warranty applies; please refer to SICK's official warranty policy.
Available Now
The SICK OLS20-UB1118340 UV LED Optical Sensor is available for immediate purchase, ideal for industrial automation and barcode detection applications.
