UV LED Sensor LUT1U-31231 | 375 nm Wavelength | IP67 Rated | High Switching Frequency | by SICK
The UV LED Sensor LUT1U-31231 is designed for industrial automation, featuring a 375 nm wavelength UV light source and a sensing distance of up to 150 mm. With a high switching frequency of 600 Hz and an 8 ms response time, this sensor is perfect for quality control and inspection systems, ensuring reliable performance in demanding environments.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: UV LED Sensor LUT1U-31231 | 375 nm Wavelength | IP67 Rated | High Switching Frequency | by SICK
Brand: SICK
SKU: 1028075
Alternatively Known As: UV LED Sensor, Light Switching Sensor, SICK UV Sensor, Industrial UV Sensor
Technical Specifications
- Sensing distance: ≤ 150 mm
- Working range: 60 mm to 160 mm
- Light source: LED, UV at 375 nm wavelength
- Light spot size: 12 mm x 12 mm
- Receiving filters: ≤ 420 nm
- Receiving range: 450 nm to 750 nm
- Supply voltage: 10 V DC to 30 V DC
- Current consumption: < 40 mA
- Switching frequency: 600 Hz
- Response time: 8 ms
- Switching output: PNP, NPN
- Output current max: 200 mA
- Connection type: Male connector M12, 5-pin
- Protection class: III
- Enclosure rating: IP67
- Housing material: Zinc diecast
- Dimensions (H x L x W): 70mm x 60mm x 23mm
- Weight: 0.24 kg
Key Features
- Sensing distance up to 150 mm
- UV LED light source with 375 nm wavelength
- Light emission from long side with 12 mm x 12 mm spot size
- Double teach-in button for easy adjustment
- PNP and NPN switching output with light switching mode
- High switching frequency of 600 Hz and fast 8 ms response time
- Protection class III with IP67 enclosure rating
- Reverse polarity and short-circuit protected outputs
Professional Installation Requirements
- Professional installation by a qualified technician or electrician is recommended to ensure proper connection and compliance with electrical standards.
Applications
- Industrial automation for object detection
- UV light sensing in manufacturing processes
- Quality control and inspection systems
Standards & Compliance
- Complies with AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Low power consumption with supply voltage from 10 V DC to 30 V DC
- Durable zinc diecast housing reduces environmental waste through long product life
- Complies with China-RoHS for hazardous substance restrictions
Warranty Information
Standard manufacturer warranty applies; please refer to SICK's official warranty policy.
Available Now
The SICK LUT1U-31231 UV LED Sensor is available for immediate purchase, ideal for industrial automation and UV sensing applications.
