UV LED Sensor LUT8U-11331 | 375 nm Wavelength | IP67 Rated | High Switching Frequency | by SICK
The UV LED Sensor LUT8U-11331 features a 375 nm ultraviolet light source, perfect for industrial automation and quality control applications. With an IP67 rating for dust and water protection, this sensor ensures reliable performance in harsh environments. Its high switching frequency of 2.5 kHz and durable zinc diecast housing make it an ideal choice for object detection and UV light sensing.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Alternatively Known As: UV LED Sensor, Ultraviolet Light Sensor, SICK UV Sensor, LUT8U Sensor
Technical Specifications
- Supply voltage: 12 V DC to 30 V DC
- Ripple: < 5 V pp
- Current consumption: < 100 mA
- Switching frequency: 2.5 kHz
- Response time: 200 µs
- Light source: LED, Ultraviolet light at 375 nm wavelength
- Light spot size: 5 mm x 15 mm
- Sensing distance: up to 50 mm
- Output function: Light switching with PNP and NPN outputs
- Protection class: II
- Circuit protection: Reverse polarity, short-circuit, interference pulse suppression
- Connection type: Plug, M12, 5-pin
- Enclosure rating: IP67
- Operating temperature: -10 °C to +55 °C
- Storage temperature: -25 °C to +75 °C
- Dimensions (H x L x W): 53mm x 80mm x 30mm
- Weight: 0.4 kg
Key Features
- Large zinc diecast housing for durability
- LED ultraviolet light source with 375 nm wavelength
- Light emission from the long side with a 5 mm x 15 mm spot size
- Manual rotary switch adjustment
- Light switching output function
- High switching frequency of 2.5 kHz
- IP67 rated enclosure for protection against dust and water
- Reverse polarity and short-circuit protected outputs
Professional Installation Requirements
- Installation should be performed by qualified personnel familiar with electrical and sensor equipment to ensure proper setup and safety compliance.
Applications
- Industrial automation for object detection
- Quality control in manufacturing
- UV light sensing in various environments
Standards & Compliance
- Complies with AS/NZS 4801 – Occupational Health & Safety Management Systems
Environmental Benefits
- Low power consumption with less than 100 mA current draw
- Durable housing reduces replacement frequency and waste
- IP67 rating ensures long service life in harsh environments
Warranty Information
Standard manufacturer warranty applies. Please refer to SICK's official warranty policy for details.
Available Now
The SICK LUT8U-11331 Ultraviolet LED Sensor is available for immediate purchase, ideal for industrial automation and quality control applications.
