UV LED Sensor LUT9U-12206 | 375 nm Wavelength | IP67 Rated | Adjustable Frequency | by SICK
The UV LED Sensor LUT9U-12206 is designed for industrial automation and quality control, featuring a 375 nm wavelength and an adjustable switching frequency of up to 6.5 kHz. With a sensing distance of 20 mm and a robust IP67 enclosure, this sensor is perfect for UV light sensing in production lines and material inspection, ensuring reliable performance in demanding environments.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: UV LED Sensor LUT9U-12206 | 375 nm Wavelength | IP67 Rated | Adjustable Frequency | by SICK
Brand: SICK
SKU: 1046749
Alternatively Known As: UV LED Sensor, UV Light Sensor, Industrial UV Sensor, SICK LUT9U Sensor
Technical Specifications
- Supply voltage: 10 V DC to 30 V DC
- Current consumption: less than 100 mA
- Switching frequency adjustable: 0.5 kHz, 2.5 kHz, 6.5 kHz
- Response time options: 1 ms, 200 µs, 75 µs
- Switching output types: PNP and NPN
- Analog output range: 0 mA to 13 mA
- Output current max: 100 mA
- Time delay switch-off adjustable: 0 ms, 10 ms, 20 ms
- Receiving filters: ≤ 420 nm
- Receiving range: 450 nm to 750 nm
- Circuit protection includes reverse polarity, short-circuit, and interference pulse suppression
- Dimensions (H x L x W): 53mm x 80mm x 30.4mm
- Weight: 0.4 kg
Key Features
- Sensing distance of 20 mm with working range from 10 mm to 40 mm
- LED UV light source with 375 nm wavelength
- Exchangeable light emission on long and short side
- Light spot size of 3 mm x 9 mm with vertical direction
- Teach-in button for static 2-point teach-in with manual fine adjustment
- Light switching output with adjustable switching frequency (0.5 kHz, 2.5 kHz, 6.5 kHz)
- Protection class II with IP67 enclosure rating
- Reverse polarity and short-circuit protected outputs
- Male connector M12, 5-pin connection type
- Operating temperature range from -10 °C to +55 °C
Professional Installation Requirements
- Installation should be performed by a qualified electrician or technician familiar with industrial sensor systems to ensure proper setup and safety compliance.
Applications
- Industrial automation for object detection
- Quality control in manufacturing
- UV light sensing in production lines
- Material inspection and sorting
Standards & Compliance
- Complies with AS/NZS 3000 – Wiring Rules (Electrical Installation)
- Complies with AS/NZS 3820 – Essential Safety Requirements for Electrical Equipment
Environmental Benefits
- Energy-efficient LED UV light source reduces power consumption
- Durable zinc diecast housing extends product lifespan, reducing waste
Warranty Information
Standard manufacturer warranty applies. Please refer to SICK's official warranty policy for details.
Available Now
The SICK LUT9U-12206 UV LED Sensor is available for immediate purchase, ideal for industrial automation and quality control applications.
