UV LED Sensor LUT9U-P124L | 375 nm Wavelength | IP67 Rated | Adjustable Frequency | by SICK
The UV LED Sensor LUT9U-P124L is designed for industrial automation and UV light sensing applications, featuring a 375 nm wavelength and an IP67 rated zinc diecast housing for robust protection. With adjustable switching frequency and response time, this sensor is perfect for quality control and inspection systems, ensuring reliable performance in demanding environments.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Supply voltage: 10 V DC to 30 V DC
- Current consumption: less than 100 mA
- Switching frequency adjustable between 0.5 kHz, 2.5 kHz, and 6.5 kHz
- Response time adjustable: 1 ms, 200 µs, 75 µs
- Output: PNP light switching with max output current 100 mA
- Connection: Male M12, 4-pin connector
- Protection class: Class II
- Enclosure rating: IP67
- Housing material: Zinc diecast
- Operating temperature range: -10 °C to +55 °C
- Storage temperature range: -25 °C to +75 °C
- Dimensions (H x L x W): 53mm x 80mm x 30.4mm
- Weight: 0.4 kg
Key Features
- Sensing distance of 20 mm with working range from 10 mm to 40 mm
- UV LED light source with 375 nm wavelength
- Long side light emission with a 3 mm x 9 mm light spot size
- Adjustable switching frequency and response time
- IP67 rated zinc diecast housing for robust protection
- IO-Link communication interface for advanced data exchange
- Reverse polarity and short-circuit protected outputs
Professional Installation Requirements
- Installation by a qualified technician or electrician is recommended to ensure proper connection and compliance with electrical standards.
Applications
- Industrial automation for object detection
- UV light sensing in manufacturing processes
- Quality control and inspection systems
Standards & Compliance
- AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Energy-efficient LED light source reduces power consumption
- Durable housing extends product lifespan, reducing waste
Warranty Information
Standard manufacturer warranty applies; please refer to SICK for specific terms.
Available Now
The SICK LUT9U-P124L UV LED Sensor is available for immediate purchase, ideal for industrial automation and UV sensing applications.
