Vari-Depth Mechanism for F Frame | Rotary Lever Handle | Left Mounting | by Eaton
The Vari-Depth mechanism for F Frame is designed for seamless integration with F-frame molded case circuit breakers. Featuring a rotary lever handle and a left mounting method, this mechanism is perfect for industrial and commercial electrical panel installations. Ensure compliance and safety with this durable and efficient solution, ideal for qualified electricians.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Vari-Depth Mechanism for F Frame | Rotary Lever Handle | Left Mounting | by Eaton
Brand: Eaton
SKU: 373D958G23
Alternatively Known As: Molded Case Circuit Breaker Handle Mechanism, Rotary Lever Handle for F Frame Breaker, Eaton G23 Handle Mechanism
Technical Specifications
- Type: Handle mechanism
- Mounting Method: Left
- Shaft Length: 6.5 inches and 10 inches
- Frame Compatibility: F-frame, Frame J-K
- Handle: Rotary lever type (handle not included)
- Product Weight: 1.05 lb (approx. 0.48 kg)
- Dimensions (H x L x W): 76mm x 157mm x 124mm
- Weight: 0.48 kg
Key Features
- Rotary lever handle mechanism
- Compatible with F-frame molded case circuit breakers
- Left mounting method
- Shaft lengths available: 6.5 inches and 10 inches
- Handle not included
Professional Installation Requirements
- Installation should be performed by a qualified electrician to ensure compliance with electrical safety standards and proper operation.
Applications
- Used with F-frame molded case circuit breakers
- Suitable for Frame J-K size circuit breakers
- Industrial and commercial electrical panel installations requiring rotary lever handle mechanisms
Standards & Compliance
- AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Durable design reduces need for frequent replacements, minimizing waste
- Supports safe and efficient electrical system operation, reducing energy loss
Warranty Information
One (1) year from the date of installation or eighteen (18) months from the date of shipment, whichever occurs first, as per Eaton Selling Policy 25-000.
Available Now
The Eaton Vari-Depth mechanism for F Frame molded case circuit breakers is available for immediate purchase, ideal for industrial and commercial electrical panel applications.
