Variable Speed Drive 4kW | IP21 Protection | Integrated EMC Filter | LCD Display | @Pack of 1 | by Clipsal
The Variable Speed Drive 4kW is designed for robust motor control in industrial applications, featuring IP21 protection and an integrated EMC filter to reduce electrical noise. With a user-friendly LCD display and multiple control modes, it's perfect for HVAC systems, pumps, and conveyor systems, ensuring energy efficiency and reduced maintenance needs.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Variable Speed Drive 4kW | IP21 Protection | Integrated EMC Filter | LCD Display | @Each of 1 | by Clipsal
Brand: Clipsal
SKU: SCHATV630U40N4
Alternatively Known As: Variable Speed Drive 4kW, VSD 4kW 400V, Clipsal ATV630U40N4, Schneider ATV630U40N4, 4kW Frequency Inverter, 4kW Motor Drive
Technical Specifications
- Power Rating: 4kW (5HP)
- Input Voltage: 3-phase 380-480V AC, 50/60Hz
- Output Voltage: 3-phase 0-480V AC
- Output Frequency: 0.1-500Hz
- IP Rating: IP21 (protected against solid objects >12mm and dripping water)
- Integrated EMC filter
- Control Modes: V/F, sensorless vector
- Display: LCD keypad
- Communication: Modbus, CANopen (expandable)
- Operating Temperature: -15°C to +50°C
- Dimensions (H x L x W): 184mm x 152mm x 140mm
- Weight: 5.5 kg
Key Features
- 4kW power rating for robust motor control
- Supports 3-phase 400V/480V input
- IP21 protection for indoor environments
- Integrated EMC filter for reduced electrical noise
- Compact design for easy panel integration
- User-friendly interface with LCD display
- Multiple control modes including V/F and sensorless vector
- Built-in safety and protection features
Professional Installation Requirements
- Installation must be performed by a licensed electrician experienced with variable speed drives and industrial motor control systems.
Applications
- Industrial automation
- Pumps and fans
- HVAC systems
- Conveyor systems
- General motor control in manufacturing
Standards & Compliance
- Complies with AS/NZS 3820 – Essential Safety Requirements for Electrical Equipment
Environmental Benefits
- Improves energy efficiency by optimizing motor speed
- Reduces mechanical wear and maintenance needs
- Lowers overall power consumption in industrial applications
Warranty Information
12 months manufacturer's warranty covering defects in materials and workmanship.
Available Now
The Clipsal VSD IP21 4KW 400V/480V (SCHATV630U40N4) is available for immediate purchase. Ideal for industrial automation, HVAC, and motor control applications.
