Varistor Surge Protection Device | 127/240V AC | DIN Rail Mount | 10kA Discharge Current | @Pack of 1 | by Clipsal
The Varistor Surge Protection Device is designed for 127/240V AC electrical systems, providing robust surge protection with a maximum discharge current of 10kA. Ideal for residential, commercial, and industrial applications, this device helps extend the lifespan of connected equipment and ensures reliable performance in switchboards and distribution boards.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Varistor Surge Protection Device | 127/240V AC | DIN Rail Mount | 10kA Discharge Current | @Each of 1 | by Clipsal
Brand: Clipsal
SKU: SCHLA4FVP
Alternatively Known As: Surge Protection Device, SPD, Clipsal Varistor, Voltage Surge Suppressor, Clipsal SCHLA4FVP
Technical Specifications
- Nominal Voltage: 127/240V AC
- Type: Varistor-based surge protection
- Mounting: DIN rail
- Response Time: <25ns
- Maximum Discharge Current: 10kA
- Operating Frequency: 50/60Hz
- Connection: Screw terminal
- Dimensions (H x L x W): 90mm x 70mm x 18mm
- Weight: 0.12 kg
Key Features
- Provides surge protection for 127/240V electrical systems
- Designed for installation in switchboards and distribution boards
- Compact and robust construction for reliable performance
- Helps extend the lifespan of connected electrical equipment
Professional Installation Requirements
- Installation must be performed by a licensed electrician in accordance with AS/NZS 3000 wiring rules.
Applications
- Residential: Protection of household electrical circuits from voltage surges
- Commercial: Safeguarding sensitive equipment in offices, retail, and hospitality environments
- Industrial: Used in switchboards and distribution boards to protect machinery and control systems
Standards & Compliance
- Complies with AS/NZS 3000 – Wiring Rules (Electrical Installation)
- Complies with AS/NZS 3820 – Essential Safety Requirements for Electrical Equipment
Environmental Benefits
- Reduces electronic waste by protecting devices from premature failure due to voltage surges
- Enhances energy efficiency by maintaining stable electrical operation
Warranty Information
12 months warranty against manufacturing defects.
Available Now
The Clipsal VARISTOR SUPPRESS.127/240 SCHLA4FVP is available for immediate purchase. Ideal for protecting electrical systems in residential, commercial, and industrial environments.
