Wall Mounted Air Conditioner 3.5kW | UV Protection & Wi-Fi Control | Inverter Technology | Haierhome
Experience efficient climate control with the 3.5kW wall mounted air conditioner, featuring UV protection, Wi-Fi smart control, and inverter technology. Ideal for single-room residential and small commercial spaces, it ensures comfort and air quality with energy-efficient performance.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Wall Mounted Air Conditioner 3.5kW | UV Protection & Wi-Fi Control | Inverter Technology | Haierhome
Brand: Haierhome
SKU: AS35PBDHRA-SET
Alternatively Known As: Pinnacle 3.5kW Wall Mounted Indoor Unit, Haierhome 3.5kW Split System, Haierhome Wall Mounted Air Conditioner
Technical Specifications
- Cooling capacity: 3.5kW
- Heating capacity: 3.7kW
- COP: 3.7
- EER: 3.8
- HSPF-RES (Hot/Average/Cold): 4.816 / 4.046 / 3.452
- Indoor airflow: 180/152/125 L/S
- Indoor sound pressure SPL: 40 / 36 / 32 / 22 dBA
- Outdoor sound power SWL: 63 dBA
- Outdoor sound pressure SPL: 53 dBA
- Refrigerant factory charge: 0.84kg R32
- Power supply: Single phase, 230V, 50Hz
- Pipe size gas: 9.52mm
- Pipe size liquid: 6.35mm
- Maximum pipe length: 15m
- Dimensions (H x L x W): 292mm x 200mm x 805mm
- Weight: 8.7 kg
Key Features
- UV Protect with built-in LED UV lights kills airborne pathogens
- Coanda Plus Airflow technology circulates air evenly up to 20 metres
- Self-Clean function freezes and flushes coils to maintain healthy airflow
- Built-in Wi-Fi smart control compatible with Google Home and Amazon Alexa
- 56°C Steri-clean and anti-bacterial silver ion coating
- Inverter controlled DC motor compressor
- Auto restart and self diagnostics
- DRED (Demand Response) ready
- Concealed LED display
- Long distance air supply up to 12 metres
- MEPS approved energy efficiency
Professional Installation Requirements
- Professional installation by a licensed HVAC technician is required to ensure correct setup, refrigerant handling, and electrical safety.
Applications
- Residential: Single-room cooling and heating
- Commercial: Small offices and retail spaces
- General: Indoor climate control for comfort and air quality
Standards & Compliance
- Complies with AS/NZS 3820 – Essential Safety Requirements for Electrical Equipment
- Complies with AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Energy-efficient inverter compressor reduces power consumption
- MEPS approved for minimum energy performance standards
- Use of R32 refrigerant with lower global warming potential
- Self-cleaning function helps maintain system efficiency and air quality
Warranty Information
5 years parts and labour warranty.
Available Now
The Haierhome Pinnacle 3.5kW Wall Mounted IDU air conditioner is available now for immediate purchase. Ideal for single-room residential and small commercial applications requiring efficient heating and cooling with smart control.
