Weatherproof Armoured Cable Gland | 20-26mm Diameter | IP66/68 Rated | Brass Construction | by Wattmaster
The Weatherproof Armoured Cable Gland is designed for 20-26mm diameter cables, providing a secure seal and high protection against water ingress with an IP66/68 rating. Made from durable brass with nickel plating, it’s perfect for both indoor and outdoor electrical installations, ensuring reliability in industrial and commercial wiring systems.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Weatherproof Armoured Cable Gland | 20-26mm Diameter | IP66/68 Rated | Brass Construction | by Wattmaster
Brand: Wattmaster
SKU: ALCAW25
Alternatively Known As: Armoured Cable Gland, Weatherproof Cable Gland, Brass Cable Gland, IP68 Cable Gland
Technical Specifications
- Cable Diameter Range: 20-26mm
- Thread Length: 14mm
- Material: Brass, Nickel Plated
- Seal Material: TPE
- Temperature Range: –20°C to +80°C
- Ingress Protection: IP66/68
- Locknut: Supplied as standard
- Compliance: AS 1939-1990
- Dimensions (H x L x W): 40mm x 50mm x 30mm
- Weight: 0.1 kg
Key Features
- Weatherproof armoured cable gland suitable for 20-26mm diameter cables
- Temperature range from –20°C to +80°C
- Provides a secure seal on cable sheath
- High degree of protection against water ingress with IP66/68 rating
- Made from brass with nickel plating for durability
- Includes locknut and TPE seal for reliable sealing
Professional Installation Requirements
- Installation should be performed by a qualified electrician to ensure proper sealing and compliance with electrical standards.
Applications
- Indoor and outdoor electrical installations
- Armoured cable sealing and protection
- Industrial and commercial wiring systems
Standards & Compliance
- Complies with AS/NZS 3000 – Wiring Rules (Electrical Installation)
- Complies with AS 1939-1990
Environmental Benefits
- Durable brass construction reduces need for frequent replacements
- Weatherproof design minimizes environmental damage and cable wear
Warranty Information
Standard manufacturer warranty applies. Please refer to Wattmaster for specific warranty details.
Available Now
The Wattmaster Weatherproof Armoured Cable Gland 20-26mm is available for immediate purchase, ideal for secure and weatherproof cable installations in industrial and commercial environments.
