Wiegand Interface 3 Readers to Suit D8X/D16X Ness

BRAND: Ness
SKU: 106-012
$34.40 List price: $45.80
+ −
30 Days Return Electricians Unlock Trade Access
Ness Wiegand interface connects 3 readers and includes wire loom and terminal blocks. Ideal for adding access control readers to D8X and D16X alarm systems.

Alternatively Known As: Ness Reader Interface Board, Ness Wiegand Reader Interface, Ness 106-012 Wiegand Interface

Technical Specifications
  • Model: 106-012
  • Interface Type: Wiegand reader termination interface
  • Reader Capacity: Up to 3 Ness addressable Wiegand readers
  • Compatible Control Panels: Ness D8X and D16X
  • Included Accessories: Wire loom, box rails and removable terminal blocks
  • Reader Compatibility: Ness 101-014 addressable Wiegand readers and compatible reader configurations
  • Country of Manufacture: Australia
  • Dimensions Basis: Estimated from the compact PCB, terminal block and wiring assembly because manufacturer dimensions were not published
  • Dimensions (H x L x W): 20mm x 100mm x 60mm
  • Weight: 0.1 kg
Key Features
  • Connects up to three readers to a compatible Ness D8X or D16X control panel
  • Provides a dedicated termination interface for reader wiring
  • Supplied with wire loom, box rails and removable terminal blocks
  • Supports individually addressed readers for multi-reader installations
  • Made in Australia by Ness
Professional Installation Requirements
  • Installation should be performed by a suitably qualified security or electrical tradesperson. Follow the Ness D8X/D16X installation manual, isolate power before wiring, and configure reader addressing and panel programming correctly.
Applications
  • Adding up to three Wiegand readers to Ness D8X alarm systems
  • Adding up to three Wiegand readers to Ness D16X alarm systems
  • Multi-reader access control and alarm arming installations
  • Connecting Ness Ultraprox 101-014 readers to compatible Ness control panels
Standards & Compliance
  • AS/NZS IEC 60839.11.1:2019 is relevant to electronic access control systems; Ness does not state product-specific conformity for the 106-012 interface.
Environmental Benefits
  • Extends existing D8X/D16X control panels with additional reader capacity, potentially avoiding full system replacement and reducing electronic waste
  • Compact modular construction limits the material required for reader expansion
  • Ness publishes corporate RoHS compliance documentation; product-specific applicability should be confirmed with the manufacturer
Warranty Information

Ness manufactured or supplied products are covered by a 3-year warranty from the date of purchase, subject to Ness warranty terms and exclusions.

Available Now

Available through Ness Corporation and authorised Australian security distributors.
