Wireless Motion Detector AJAX MOTIONPROTECT PLUS | PIR & K-Band Sensors | 12m Detection Range | by AJAX
The AJAX MOTIONPROTECT PLUS Wireless Motion Detector is designed for effective home and office security, featuring advanced PIR and K-band microwave sensors for precise motion detection. With a detection range of up to 12 meters and a horizontal viewing angle of 88.5°, it filters out false alarms caused by pets and environmental factors. Ideal for residential and commercial applications, this detector ensures reliable performance with a battery life of up to 5 years.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Wireless Motion Detector AJAX MOTIONPROTECT PLUS | PIR & K-Band Sensors | 12m Detection Range | by AJAX
Brand: AJAX
SKU: 30660.02.WH3
Alternatively Known As: Wireless Motion Sensor, PIR Motion Detector, Microwave Motion Sensor, Home Security Motion Detector
Technical Specifications
- Sensitive element: PIR sensor and K-band microwave sensor
- Motion detection distance: up to 12 m (installed at 2.4 m height)
- Motion detection angle: horizontal 88.5°
- Motion detection speed: 0.3 to 2 m/s
- Sensitivity: 3 levels
- Pet immunity: weight up to 20 kg, height up to 50 cm
- False alarm prevention: SmartDetect software algorithm
- Temperature compensation: effective detection from −10 °C to +40 °C
- Wireless communication range: up to 1200 m
- Battery: 1 × CR123A
- Calculated battery life: up to 5 years
- Operating temperature range: from −10 °C to +40 °C
- Operating humidity: up to 75%
- Protection class: IP50
- Dimensions (H x L x W): 110mm x 50mm x 65mm
- Weight: 0.096 kg
Key Features
- Wireless motion detector with PIR and K-band microwave sensors
- Detection distance up to 12 m with 88.5° horizontal viewing angle
- Two-way encrypted communication with control panel up to 1,200 m range
- Filters false alarms from air conditioners and curtain movements
- Pet immunity for animals up to 20 kg and 50 cm height
- Up to 5 years battery life on pre-installed CR123A battery
- SmartDetect software algorithm to prevent false alarms
- Quick pairing with security system via QR code within 30 seconds
- Mobile and desktop apps for adjustment, testing, and control
- Tampering alarm for added security
- Grade 2 EN 50131 PD 6662:2017 certified
Professional Installation Requirements
- Professional installation by a qualified security technician or electrician is recommended to ensure optimal sensor placement and system integration.
Applications
- Home security: Detects intrusions in residential settings
- Office security: Monitors office spaces for unauthorized access
- Suitable for rooms with air conditioners, fireplaces, and areas with light flickering or reflections
Standards & Compliance
- Complies with AS/NZS 4801 – Occupational Health & Safety Management Systems
Environmental Benefits
- Long battery life reduces battery waste and replacement frequency
- Wireless design minimizes installation impact and material use
Warranty Information
24 months warranty provided by the manufacturer.
Available Now
The AJAX MOTIONPROTECT PLUS Wireless Motion Detector White is available for immediate purchase, ideal for enhancing security in residential and commercial environments.
