Wireless Radio Reed Switch 304MHz Vibration Sensor 9V Battery Ness

BRAND: Ness
SKU: 100-527
$143.90 List price: $191.80
+ −
30 Days Return Electricians Unlock Trade Access
Ness wireless radio reed switch features 304MHz operation, 9V battery power and a vibration sensor. Ideal for wireless alarm systems.

Alternatively Known As: Ness Large Radio Reed, Ness Universal Transmitter, Wireless Magnetic Contact, Wireless Shock or Vibration Sensor

Technical Specifications
  • Radio Frequency: 303.85MHz nominal 304MHz
  • Operating Voltage: 9V lithium battery
  • Quiescent Current: Less than 10µA
  • Transmit Power: 100µW
  • Radio Security: Encrypted and supervised operation with compatible Ness receivers
  • Inputs: Internal reed switch or external normally closed device
  • External Input Cable Length: Maximum 400mm
  • Vibration Sensitivity: Rotary minimum-to-maximum adjustment
  • Transmitted Signals: Alarm, restore, tamper, low battery and learn message
  • Compatibility: Ness radio receivers
  • Dimensions: 78H x 73W x 27Dmm
  • Dimensions (H x L x W): 78mm x 73mm x 27mm
  • Weight: 0.15 kg
Key Features
  • Built-in magnetic reed switch for door and window monitoring
  • Integrated vibration analyser for wireless shock detection
  • Operates from a 9V lithium battery
  • Adjustable vibration sensitivity
  • Supports internal reed, external switch or combined input configuration
  • Cover tamper switch
  • Low-battery reporting
  • Encrypted and supervised radio signals with compatible Ness receivers
  • Matching magnet supplied
Professional Installation Requirements
  • Installation, programming and testing should be completed by a suitably trained security alarm technician. The transmitter must be enrolled to a compatible Ness receiver and installed in accordance with the alarm system manufacturer's instructions and applicable Australian requirements.
Applications
  • Wireless intruder alarm systems
  • Door, window, drawer and access-panel monitoring
  • Roller door and garage-door security
  • Wireless vibration or shock detection on doors, windows and vulnerable surfaces
  • Connection of external normally closed reed switches, emergency buttons or Nessensor vibration sensors
Standards & Compliance
  • Relevant system standard: AS/NZS 2201.1 for the design, installation, commissioning and maintenance of intruder alarm systems
  • Relevant transmission-system standard: AS/NZS 2201.5 for alarm transmission systems, where applicable to the completed installation
Environmental Benefits
  • Low standby current helps extend battery replacement intervals
  • Replaceable battery design supports servicing without replacing the complete sensor
  • Ness publishes RoHS compliance documentation for its product range
  • Durable electronic construction can reduce replacement waste over the service life
Warranty Information

Ness manufactured or supplied products are covered by a 3-year warranty from the date of purchase, unless otherwise specified. Warranty claims are subject to Ness conditions and exclusions.

Available Now

Available through Ness Corporation and authorised Australian security-system distributors.
