Wireless Water Shutoff Valve 3/4" Black | Remote Control | Automatic Leak Detection | by Dicker Data
The Wireless Water Shutoff Valve 3/4" Black is designed for efficient leak prevention in residential and commercial plumbing systems. With remote control via Ajax apps and automatic shutoff within 5 seconds of leak detection, it ensures peace of mind. Built for durability with brass construction, this valve operates in temperatures from -20 °C to +170 °C, making it ideal for various water supply and heating applications.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Wireless Water Shutoff Valve 3/4" Black | Remote Control | Automatic Leak Detection | by Dicker Data
Brand: Dicker Data
SKU: 62605.155.BL3
Alternatively Known As: Wireless Water Shutoff Valve, Remote Water Valve, Smart Water Stop Valve, Ajax WaterStop Valve
Technical Specifications
- Valve size: ¾" (DN 20)
- Valve material: Brass
- Connection type and thread: BSP parallel (EN 10226-1, ISO 228), female-to-female threads
- Operating fluid: Hot and cold water, non-aggressive liquids
- Operating liquid temperature range: -20 °C to +170 °C
- Operating pressure: Up to 10 bars
- Shut-off speed: Up to 7 seconds
- Torque: Up to 8.5 N•m
- Remote control and configuration via Ajax apps
- Manual control: Lever on mounting platform and control button on electric actuator
- Overheating notification sent at +60 °C
- Radio signal range: Up to 1,100 m
- Power supply: 4 × CR123A batteries with up to 3 years battery life
- Optional external power supply: 7.5–14 V⎓, from 1.8 A
- Operating temperature range: 0 °C to +60 °C
- Operating humidity: Up to 95%
- Dimensions (H x L x W): 70mm x 150mm x 104mm
- Weight: 1.0 kg
Key Features
- Remote control of water supply via Ajax apps from anywhere with Internet access
- Automatic water shutoff within 5 seconds upon leak detection
- Supports automation scenarios by leak alarm, security mode change, and schedule
- Adjustable stuck prevention with a maximum interval of 1 week
- Up to 1,100 m radio signal range without obstacles
- Manual control via lever on mounting platform and button on electric actuator
- Mounting lockers to prevent unauthorized disassembly
- Optional external power supply connection (9–12 V⎓, 2 A)
- Pairing with system via QR code
- Compatible with ISO 5211 standard shutoff valves
Professional Installation Requirements
- Professional installation by a qualified plumber and electrician is recommended to ensure proper integration with water and electrical systems.
Applications
- Water supply and heating systems
- Remote water shutoff for leak prevention
- Residential and commercial plumbing systems
Standards & Compliance
- Complies with AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Prevents water wastage by automatically shutting off water during leaks
- Supports energy-efficient operation with long battery life and optional external power
- Helps reduce water damage and associated environmental impact
Warranty Information
24 months warranty.
Available Now
The AJAX WaterStop Wireless Water Shutoff Valve 3/4" Black is available for immediate purchase, ideal for residential and commercial water leak prevention and control.
