WLA4SP-1H163130A00 | Photoelectric sensors
The SICK WLA4SP-1H163130A00 is a high-performance photoelectric retro-reflective sensor designed for precise object detection in industrial automation, featuring IO-Link communication and robust IP66/IP67 protection.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: WLA4SP-1H163130A00 | Photoelectric sensors
Brand: SICK
SKU: 1140054
Alternatively Known As: Photoelectric sensor, Retro-reflective sensor, SICK photoelectric sensor, IO-Link sensor, Industrial object sensor
Technical Specifications
- Functional principle: Photoelectric retro-reflective sensor without reflector minimum distance
- Sensing range: 0 m to 7.1 m, recommended 0 m to 5 m
- Light source: PinPoint LED, visible red light, 635 nm wavelength
- LED risk group: Free group according to EN 62471 and IEC 62471
- Supply voltage: 10 V DC to 30 V DC
- Current consumption: ≤ 20 mA at 24 V
- Digital outputs: 2 push-pull (PNP/NPN), dark switching
- Response time: ≤ 500 µs, switching frequency up to 1000 Hz
- Protection class: III
- Enclosure rating: IP66 and IP67
- Operating temperature: -40 °C to +60 °C
- Connection: 4-wire cable, 2 m length
- Housing material: Plastic VISTAL®, front screen PMMA
- Shock resistance: 30 g, 11 ms
- Vibration resistance: 10 Hz to 1000 Hz, amplitude 1 mm
- Communication: IO-Link V1.1 with COM2 (38.4 kBaud), cycle time 2.3 ms
- Smart Task functions: Base logics with AND, OR, timer functions, inverter
- Dimensions (H x L x W): 42mm x 19mm x 12mm
- Weight: 0.1 kg
Key Features
- Photoelectric retro-reflective sensor with autocollimation/coaxial optics
- Sensing range up to 7.1 m with recommended range 0 to 5 m
- PinPoint LED visible red light with 635 nm wavelength
- BluePilot teach-in button for sensitivity adjustment
- IO-Link V1.1 interface for sensor configuration and Smart Task functions
- Dual push-pull digital outputs (PNP/NPN) with dark switching
- High protection class III with IP66 and IP67 enclosure rating
- Robust plastic VISTAL® housing with slim design
- Operating temperature range from -40 °C to +60 °C
- Shock resistance 30 g and vibration resistance 10 Hz to 1000 Hz
- LED indicators for alignment, power, IO-Link mode, and light beam status
- Alarm output configurable via IO-Link
- Long LED service life of 100,000 hours at 25 °C
Professional Installation Requirements
- Installation by qualified personnel is recommended to ensure proper electrical connection and configuration via IO-Link for optimal sensor performance.
Applications
- Object detection in industrial automation
- Detecting objects wrapped in film
- Use in harsh environments requiring IP66/IP67 protection
- Automation processes requiring precise sensing up to 7.1 meters
Standards & Compliance
- Complies with AS/NZS 60950 – Safety of IT and Communication Equipment
Environmental Benefits
- Long LED service life reduces waste and replacement frequency
- Energy-efficient operation with low current consumption
- Robust design minimizes environmental impact through durability
Warranty Information
Standard manufacturer warranty applies. Please refer to SICK's official warranty policy for details.
Available Now
The SICK WLA4SP-1H163130A00 Photoelectric Sensor is available for immediate purchase, ideal for industrial automation and object detection applications.
