XL³ Solid Faceplate 800 | IP55 Rated | IK08 Impact Resistance | RAL 7035 Finish | @Each of 1 | by Legrand
The XL³ Solid Faceplate 800 is designed for robust electrical distribution, featuring IP55 dust and water protection and IK08 impact resistance. Ideal for industrial and urban indoor installations, this metal enclosure supports devices up to 630 A and is fireproof to 750°C for 5 seconds, ensuring safety and reliability in demanding environments.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: XL³ Solid Faceplate 800 | IP55 Rated | IK08 Impact Resistance | RAL 7035 Finish | @Each of 1 | by Legrand
Brand: Legrand
SKU: 20449
Alternatively Known As: XL3 800 Distribution Enclosure, Legrand XL3 Solid Faceplate, XL³ 800 Cabinet Faceplate
Technical Specifications
- IP Rating: IP55 for dust and water protection
- Impact Resistance: IK08 on door
- Material: Metal enclosure with RAL 7035 finish
- Plinth Color: RAL 7004
- Device Capacity: Up to 630 A
- Fire Resistance: 750°C for 5 seconds (IEC 60695-2-1)
- Module Capacity: 24 and 36 modules per row
- Installation: Can be joined horizontally
- Dimensions (H x L x W): 1200mm x 300mm x 800mm
- Weight: 15 kg
Key Features
- IP55 rated distribution cabinet with cable sleeves and doors
- IK08 impact resistance on door
- Metal enclosure finished in RAL 7035 with plinths in RAL 7004
- Supports devices up to 630 A
- Fireproof to 750°C for 5 seconds according to IEC 60695-2-1
- Modular capacity of 24 and 36 modules per row
- Can be joined horizontally for expanded installations
- Suitable for industrial and urban indoor use
Professional Installation Requirements
- Installation should be performed by a qualified electrician to ensure compliance with electrical standards and safety regulations.
Applications
- Industrial and urban indoor electrical installations
- Public building electrical distribution
- Electrical distribution boards and enclosures requiring IP55 protection
Standards & Compliance
- AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Durable metal construction reduces need for frequent replacements
- Fireproof design enhances safety and reduces risk of fire damage
- Modular design allows for scalable installations minimizing waste
Warranty Information
1 year warranty against manufacturing defects.
Available Now
Legrand XL³ Solid Faceplate 800 with hinges and locks is available for immediate purchase, ideal for industrial and public building electrical distribution applications.
