XLPE Aluminium 120mm 4 Core Cable | UV Stabilised | Halogen Free | @KM of 0.10 | by Electra Cables
The XLPE Aluminium 120mm 4 Core Cable is designed for high current capacity in power distribution applications. With a UV stabilised sheath and halogen-free insulation, it ensures safety and durability in both commercial and industrial settings. Ideal for underground and overhead mains power supply, this cable is compliant with AS/NZS standards, making it a reliable choice for licensed electricians.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: XLPE Aluminium 120mm 4 Core Cable | UV Stabilised | Halogen Free | @KM of 0.10 | by Electra Cables
Brand: Electra Cables
SKU: ALX41200-B
Alternatively Known As: 120mm 4 Core Aluminium XLPE Cable, ALX41200-B, 4C 120mm2 Aluminium Power Cable, XLPE Insulated Aluminium Cable
Technical Specifications
- Conductor: Aluminium, stranded
- Insulation: Cross-linked Polyethylene (XLPE)
- Number of Cores: 4
- Nominal Area: 120mm² per core
- Voltage Rating: 0.6/1kV
- Sheath: UV stabilised, black
- Operating Temperature: -25°C to +90°C
- Standard: AS/NZS 5000.1
- Flame Retardant: Yes
- Halogen Free: Yes
- Dimensions (H x L x W): 45mm x 1000mm x 45mm
- Weight: 4.5 kg
Key Features
- XLPE insulated aluminium conductor for high current capacity
- 4 core design for three-phase and neutral applications
- UV stabilised and suitable for direct burial
- Low smoke, halogen free insulation for enhanced safety
- High resistance to moisture, chemicals, and abrasion
Professional Installation Requirements
- Installation must be carried out by a licensed electrician in accordance with AS/NZS 3000 and local regulations. Proper cable handling and termination tools are required.
Applications
- Power distribution in commercial and industrial installations
- Underground and overhead mains power supply
- Suitable for use in switchboards and substations
Standards & Compliance
- Complies with AS/NZS 5000.1 for power cables with extruded insulation and their accessories for rated voltages from 1.9/3.3 kV up to and including 19/33 kV
- Complies with AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Low smoke, halogen free insulation reduces toxic emissions in case of fire
- Aluminium conductor is lightweight and recyclable
- Durable design reduces need for frequent replacement
Warranty Information
12 months manufacturer's warranty against defects in materials and workmanship.
Available Now
The Electra Cables XLPE Aluminium 120mm 4 Core Power Cable (ALX41200-B) is available for immediate purchase. Ideal for commercial and industrial power distribution applications.
