Zinc Plated Shackle SHKL A SZ01 | 100 kg Load Capacity | Curved Design | @Pack of 25 | by Wurth
The Zinc Plated Shackle SHKL A SZ01 is designed for reliable towing and securing applications, featuring a robust 100 kg load capacity and a corrosion-resistant zinc-plated steel construction. Ideal for automotive and industrial use, this shackle ensures secure connections for towing motor vehicles and lengthening ropes and chains, making it a must-have for professionals.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Zinc Plated Shackle SHKL A SZ01 | 100 kg Load Capacity | Curved Design | @Pack of 25 | by Wurth
Brand: Wurth
SKU: 52301
Alternatively Known As: Towing Shackle, Zinc Plated Shackle, Steel Shackle, Connection Shackle
Technical Specifications
- Load capacity: 100 kg
- Thread type x shackle bolt diameter: M5
- Shackle internal width (b1): 7 mm
- Shackle external width (b2): 15 mm
- Shackle diameter (d1): 5 mm
- Shackle-bolt diameter (d2): 5 mm
- Internal shackle height (centre bolt) (h1): 18 mm
- Design: Curved
- Material: Steel
- Surface: Zinc plated
- Form: A
- Nominal size: 0.1
- RoHS-compliant: Yes
- Dimensions (H x L x W): 18mm x 25mm x 15mm
- Weight: 0.05 kg
Key Features
- Zinc-plated steel for corrosion resistance
- Curved design for sizes M5 to M12
- Forged design for sizes M16 to M48
- Hot-dip galvanized from M48 size
- RoHS-compliant
Professional Installation Requirements
- Installation by a qualified professional is recommended to ensure safe and secure towing connections.
Applications
- Connection element for towing motor vehicles
- Lengthening ropes and chains
Standards & Compliance
- Complies with AS/NZS 1170 – Structural Design Actions (Wind, Earthquake, Snow Loads)
Environmental Benefits
- Zinc plating provides corrosion resistance, extending product life and reducing waste.
Warranty Information
Standard manufacturer warranty applies.
Available Now
The Wurth Shackle SHKL A SZ01 BT ZN PIN50 25 PCS is available now for immediate purchase. Ideal for towing and securing applications in automotive and industrial settings.
