16 Channel Video Decoder | 4K HDMI Input | 256 Video Decoding Channels | by HIKVISION
The 16 Channel Video Decoder with 4K HDMI input and 256 video decoding channels is perfect for advanced video surveillance systems. Designed for security monitoring centers and video wall displays, it supports multiple formats and network protocols, ensuring seamless integration and optimal performance. With remote management capabilities and dual audio channel support, this decoder is built for professionals seeking reliable video management solutions.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: 16 Channel Video Decoder | 4K HDMI Input | 256 Video Decoding Channels | by HIKVISION
Brand: HIKVISION
SKU: DS-6916UDI-C
Alternatively Known As: 16 Channel Video Decoder, HIKVISION Video Wall Decoder, DS-6916UDI-C Video Processor
Technical Specifications
- Video Input: Supports 4K HDMI signal input, network cameras, NVRs.
- Audio Input: Embedded HDMI audio input, 16 bit, 48 KHz or 32 KHz sampling rate, dual channel stereo.
- Video Output: 4K UHD (3840 × 2160@30 Hz) via HDMI 1.4 port.
- Decoding Capacity: 256 video decoding channels; supports 128 channels of 2 MP or 256 channels of 720p video.
- Supported Formats: H.264, H.265, Smart264, Smart265, MJPEG, HIK264; audio decoding includes G.722, G.711A/U, G.726, MPEG2-L2, AAC, MP3, PCM.
- Video Wall: Supports up to 64 scenes, multiple window divisions, PTZ control, and video recording playback.
- Network Protocols: IPv4, IPv6, ONVIF, RTP, RTSP.
- Maintenance: Remote parameter configuration, system logs, firmware upgrades, failure detection and alarms.
- Dimensions (H x L x W): 88mm x 350mm x 440mm
- Weight: 5 kg
Key Features
- Supports video input from computers, video conference terminals, and 4K HDMI signals.
- Supports network cameras, NVRs, and other network signal sources.
- Embedded HDMI audio input and output with dual audio channel support.
- Supports 256 video decoding channels and simultaneous decoding of 128 channels of 2 MP video or 256 channels of 720p video.
- Supports H.264, H.265, Smart264, Smart265, MJPEG, and HIK264 encoding and decoding formats.
- Supports video wall functions including splicing signal sources, window roaming, scene switching, and PTZ control.
- Supports ONVIF protocol and integration with multiple decoding devices via SDK.
- Supports IPv4 and IPv6 protocols with simultaneous access.
- Remote device management including parameter configuration, system logs, and firmware upgrades.
- Failure auto detection and alarm for network disconnection, IP conflict, and device exceptions.
Professional Installation Requirements
- Installation and configuration should be performed by qualified security system professionals or network technicians to ensure proper integration and optimal performance.
Applications
- Video surveillance systems
- Security monitoring centers
- Video wall display setups
- Network video decoding and management
Standards & Compliance
- AS/NZS 60950 – Safety of IT and Communication Equipment
Environmental Benefits
- Supports efficient video decoding reducing the need for multiple devices, lowering energy consumption.
- Enables centralized video management which can optimize resource use and reduce electronic waste.
Warranty Information
3 years warranty provided by the manufacturer.
Available Now
The HIKVISION DS-6916UDI-C 16 Channel Decoder is available for immediate purchase, ideal for advanced video surveillance and security monitoring applications.
