16mm Liquid Tight 90 Degree IP66 M20 Nickel-Plated Brass Cabac
Cabac Liquid Tight Conduit Fitting 90 Degree IP66 Rated M20 External Thread features Nickel plated brass connector body and hexagonal nut construction,...
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Material: Nickel plated brass connector body and hexagonal nut
- Sealing ring: Nylon 66
- Ferrule: Galvanised steel
- Thread size: M20 x 1.5
- Conduit size: 16mm
- Tested and Certified to IEC60079-0: 2007-10 and IEC60079-31: 2008
- Ex ta IIIC IP66 Hazardous Area Type Protection
- IEC Ex TSA 11.0026 Hazard Area Certification Number
- Dimensions (H x L x W): 56mm x 36mm x 32mm
- Weight: 0.1 kg
Key Features
- Nickel plated brass construction for superior durability
- 90-degree male thread fitting with external thread for threaded entries and knockouts
- High chemical resistance and mechanical strength
- Dust proof and liquid tight seal
- Complete with sealing ring and flanged grounding cone for excellent pull-out strength
- One-piece installation with swivel on conduit until tightened
Professional Installation Requirements
- Professional installation by a qualified electrician or technician is recommended to ensure compliance with hazardous area standards and secure fitting.
Applications
- Machining centres and robotics
- General wiring for OEM applications
- Low fire hazard applications
- Underfloor wiring in office buildings
- Narrow space static installations
Standards & Compliance
- AS/NZS 60035 – Electrical Equipment in Explosive Atmospheres
Environmental Benefits
- Durable nickel plating extends product life reducing waste
- Provides secure sealing to prevent ingress of dust and liquids, protecting electrical systems and reducing maintenance
Warranty Information
Standard manufacturer warranty applies. Please refer to Cabac warranty terms for details.
Available Now
The Cabac Nickel Plated Brass Liquid Tight 90 Degree Fitting M20 is available for immediate purchase, ideal for industrial and commercial wiring protection applications.
FAQ
Q: What conduit size is this fitting designed for?
A: This fitting is designed for 16mm conduit and uses an M20 x 1.5 external thread.
Q: Is this conduit fitting suitable for hazardous area installations?
A: Yes. It is tested and certified to IEC60079-0, IEC60079-31 and complies with AS/NZS 60035 for hazardous area electrical installations.
Pair this installation with a liquid tight conduit fitting 45 degree where a smoother conduit entry angle is required.
A liquid tight conduit fitting stainless steel option is available for applications requiring corrosion resistant conduit connections.
Install alongside an inspection tee to simplify future conduit inspection and maintenance access.
Review the conduit fittings Australia guide to understand common conduit fitting types and installation applications.
