2 Way Coaxial Tap 20 dB | 5-2400 MHz | Power Pass 30V 2A | Solder Shielded by Jonsa
2 way coaxial tap with 20 dB and 5-2400 MHz range—ideal for telecommunications and broadcasting. Built for efficient signal distribution, with power pass 30V 2A and solder shielded design.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: TAP 2 WAY 20 DB, 5...2400 MHz POWER PASS OUT-IN 30V 2A
Brand: Jonsa
SKU: CAS2TF20
Alternatively Known As: 2 Way Tap, Signal Splitter, Coaxial Tap
Technical Specifications
- Insertion Loss IN-OUT: 5 … 40 MHz - 12 dB = ≤ 2.2
- Isolation TAP-TAP: ≥ 30 dB for 5 ... 40 MHz
- Power Pass: Output > Input, 30 VDC 2 Amp
- Impedance: 75 Ω
- Housing: Solder Shielded Bottom Plate
- Mounting Screws: ± PM 4 x 18 A3 Nickel-Plated, 2 pcs
- Dimensions (H x L x W): 50mm x 100mm x 100mm
- Weight: 0.5 kg
Key Features
- Insertion Loss IN-OUT: 5 … 40 MHz - 12 dB = ≤ 2.2
- Isolation TAP-TAP: ≥ 30 dB for 5 ... 40 MHz
- Power Pass: Output > Input, 30 VDC 2 Amp
- Impedance: 75 Ω
Professional Installation Requirements
- Professional installation by a qualified technician is recommended for optimal performance.
Applications
- Telecommunications: Signal distribution in residential and commercial settings
- Broadcasting: Used in cable TV and satellite systems
Standards & Compliance
- Complies with AS/NZS 60950 for safety of IT and communication equipment.
Environmental Benefits
- Efficient signal distribution reduces energy waste in broadcasting systems.
Warranty Information
1 year warranty against manufacturing defects.
Available Now
The Jonsa TAP 2 WAY 20 DB is available now for immediate purchase. Ideal for telecommunications and broadcasting applications.
