2-Way F-Type Splitter 5-2200MHz All Ports Power Pass White Jonsa

BRAND: Jonsa
SKU: DS/VTS525
$131.70 List price: $175.50
+ −
30 Days Return Electricians Unlock Trade Access
Jonsa 2-Way F-Type splitter features 5-2200MHz frequency range, all-port power pass. Ideal for residential and commercial TV satellite signal distribution.
Technical Specifications
  • Inputs SAT-IF / TERR-RF: 4 / 1
  • Outputs SAT-IF / TERR-RF: 4 / 1 + 4 / 1
  • Frequency Range: 5 … 862 MHz and 950 … 2200 MHz
  • Through Loss Terr-RF: 4 dB
  • Through Loss SAT-IF: 5 dB
  • Isolation Input / Input: > 26 dB
  • Isolation Output / Output TERR-RF: > 20 dB
  • Isolation Output / Output SAT-IF: > 15 dB
  • Max DC-Through: 30 V / 1 A
  • Ambient Temperature: -20 ... +50 °C
  • Dimensions (H x L x W): 46mm x 145mm x 130mm
  • Weight: 0.5 kg
Key Features
  • Standby functionality
  • Earth & clamp fitted
  • High port to port isolation
  • DC power passing on all ports
Professional Installation Requirements
  • Professional installation is recommended for optimal performance and safety.
Applications
  • Commercial: Suitable for use in various commercial settings requiring signal distribution.
Standards & Compliance
  • Complies with AS/NZS 60950 for safety of IT and communication equipment.
Environmental Benefits
  • Efficient signal distribution reduces energy waste in commercial setups.
Warranty Information

1 year warranty against manufacturing defects.

Available Now

The Jonsa 2 Way 5 Wire F Type Splitter 5-2200MHz is available now for immediate purchase. Ideal for commercial applications requiring reliable signal distribution.
