2 Way F Type Splitter 5-2200MHz | High Port Isolation | DC Power Passing by Jonsa
2 way F type splitter with 5-2200MHz frequency range and high port isolation—ideal for commercial signal distribution. Built for efficient performance, with DC power passing on all ports.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: SPLITTER 2 WAY 5 WIRE F TYPE 5-2200MHZ
Brand: Jonsa
SKU: DS/VTS525
Alternatively Known As: 2 Way F Type Splitter, 5 Wire Splitter, Signal Splitter
Technical Specifications
- Inputs SAT-IF / TERR-RF: 4 / 1
- Outputs SAT-IF / TERR-RF: 4 / 1 + 4 / 1
- Frequency Range: 5 … 862 MHz and 950 … 2200 MHz
- Through Loss Terr-RF: 4 dB
- Through Loss SAT-IF: 5 dB
- Isolation Input / Input: > 26 dB
- Isolation Output / Output TERR-RF: > 20 dB
- Isolation Output / Output SAT-IF: > 15 dB
- Max DC-Through: 30 V / 1 A
- Ambient Temperature: -20 ... +50 °C
- Dimensions (H x L x W): 46mm x 145mm x 130mm
- Weight: 0.5 kg
Key Features
- Standby functionality
- Earth & clamp fitted
- High port to port isolation
- DC power passing on all ports
Professional Installation Requirements
- Professional installation is recommended for optimal performance and safety.
Applications
- Commercial: Suitable for use in various commercial settings requiring signal distribution.
Standards & Compliance
- Complies with AS/NZS 60950 for safety of IT and communication equipment.
Environmental Benefits
- Efficient signal distribution reduces energy waste in commercial setups.
Warranty Information
1 year warranty against manufacturing defects.
Available Now
The Jonsa 2 Way 5 Wire F Type Splitter 5-2200MHz is available now for immediate purchase. Ideal for commercial applications requiring reliable signal distribution.
