2 Way Signal Tap 12 dB | 5-2400 MHz | Power Pass 30V 2A | Solder Shielded by Jonsa
2 way signal tap with 12 dB insertion loss and 5-2400 MHz frequency range—ideal for telecommunications and broadcasting. Built for efficient signal distribution, with power pass output and solder shielded design.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: TAP 2 WAY 12 DB, 5...2400MHZ POWER PASS OUT-IN 30V 2A
Brand: Jonsa
SKU: CAS2TF12
Alternatively Known As: 2 Way Splitter, Signal Tap, RF Tap
Technical Specifications
- Frequency Range: 5 … 2400 MHz
- Insertion Loss IN-OUT: 5 … 40 MHz - 12 dB = ≤ 2.2
- Isolation TAP-TAP: 5 ... 40 MHz ≥ 30 dB
- Impedance: 75 Ω
- Housing: Solder Shielded Bottom Plate
- Power Pass: Output > Input, 30 VDC 2 Amp
- Dimensions (H x L x W): 50mm x 100mm x 100mm
- Weight: 0.5 kg
Key Features
- Insertion Loss IN-OUT: 5 … 40 MHz - 12 dB = ≤ 2.2
- Isolation TAP-TAP: 5 ... 40 MHz ≥ 30 dB
- Power Pass Output > Input, 30 VDC 2 Amp
Professional Installation Requirements
- Professional installation by a qualified technician is recommended for optimal performance.
Applications
- Telecommunications: Signal distribution in residential and commercial setups
- Broadcasting: Used in cable TV and satellite systems
Standards & Compliance
- Complies with AS/NZS 60950 for safety of IT and communication equipment.
Environmental Benefits
- Efficient signal distribution reduces energy waste in telecommunications.
Warranty Information
1 year warranty against manufacturing defects.
Available Now
The Jonsa TAP 2 WAY 12 DB is available now for immediate purchase. Ideal for telecommunications and broadcasting applications.
