3 Phase Circuit Breaker 100A | 15kA Breaking Capacity | Screw Terminal | HMC390T by Hager

BRAND: :hager
SKU: HMC390T
$491.20 List price: $628.10
+
3-phase circuit breaker with 100A rated current and 15kA breaking capacity—ideal for residential and commercial electrical systems. Built for secure installation with screw terminals, ensuring reliable performance in various climates.

Product Name/Title: MCB 3P 15kA C-100A 4.5M

Brand: Hager

SKU: HMC390T

Alternatively Known As: Miniature Circuit Breaker, MCB, 3 Phase Circuit Breaker, HMC390T

Technical Specifications
  • Rated operational voltage: 415V AC
  • Rated insulation voltage: 500V
  • Rated impulse withstand voltage: 6000V
  • Frequency: 50 - 60 Hz
  • Nominal tightening torque: 3.5 - 5.0 Nm
  • Electric current: Rated current 100A
  • Endurance: 4000 electrical operations, 20000 mechanical operations
  • Cross-section of input/output: 1 - 70 mm² for massive conductors, 1 - 50 mm² for flexible conductors
  • Dimensions (H x L x W): 90mm x 70mm x 80mm
  • Weight: 0.5 kg
Key Features
  • 3-pole design for three-phase systems.
  • Rated current of 100A with a breaking capacity of 15kA.
  • Screw terminal connections for secure installation.
  • Suitable for use in various climates.
Professional Installation Requirements
  • Professional installation by a qualified electrician is recommended for optimal safety.
Applications
  • Residential: Homes, apartments, and small buildings
  • Commercial: Offices, retail spaces, and industrial applications
Standards & Compliance
  • Complies with AS/NZS 60947-2 for circuit breakers.
Environmental Benefits
  • RoHS and REACH compliant, contributing to reduced environmental impact.
Warranty Information

2 years warranty against manufacturing defects.

Available Now

The Hager MCB 3P 15kA C-100A 4.5M is available now for immediate purchase. Ideal for residential and commercial electrical systems.

HMC390T (HMC390T, 188 Kb) [Download]

(PEP_HAGER_HAGE-00715-V01.01-EN_23092022.pdf, 377 Kb) [Download]

reach_declaration_HMC390T5.pdf (reach_declaration_HMC390T5.pdf, 103 Kb) [Download]

rohs_declaration_HMC390T5.pdf (rohs_declaration_HMC390T5.pdf, 104 Kb) [Download]

(DECLARATION_21_2310_07_21.pdf, 101 Kb) [Download]

(DECLARATION_23_3059_05_2023.pdf, 439 Kb) [Download]

(DECLARATION_23_2310_05_23.pdf, 455 Kb) [Download]
