3 Phase Circuit Breaker 80A | 10kA Breaking Capacity | Compact Design by Hager
3 phase circuit breaker with 80A rated current and 10kA breaking capacity—ideal for residential, commercial, and industrial applications. Built for high endurance with 20,000 mechanical operations and secure screw terminal connections.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: MCB 3P 10kA C-80A 4.5M
Brand: Hager
SKU: HMF380T
Alternatively Known As: Miniature Circuit Breaker, MCB, 3 Phase Circuit Breaker, HMF380T
Technical Specifications
- Type of pole: 3P
- Rated operational voltage: 415V AC
- Rated current: 80A
- Rated short-circuit breaking capacity: 10kA
- Nominal tightening torque: 3.5 - 5.0 Nm
- Electric endurance: 4000 cycles
- Mechanical operations: 20000 cycles
- Cross-section for massive conductors: 1 - 70 mm²
- Cross-section for flexible conductors: 1 - 50 mm²
- Degree of pollution: 3
- Dimensions (H x L x W): 90mm x 70mm x 80mm
- Weight: 0.5 kg
Key Features
- 3-pole design for three-phase systems.
- Rated current of 80A with a breaking capacity of 10kA.
- Screw terminal connections for secure installation.
- High endurance with 20,000 mechanical operations.
Professional Installation Requirements
- Professional installation by a qualified electrician is recommended for optimal safety.
Applications
- Residential: Homes, apartments, and small buildings
- Commercial: Offices and retail spaces
- Industrial: Factories and manufacturing facilities
Standards & Compliance
- Complies with AS/NZS 60898 for safety and performance standards.
Environmental Benefits
- RoHS and REACH compliant, contributing to reduced environmental impact.
Warranty Information
2 years warranty against manufacturing defects.
Available Now
The Hager MCB 3P 10kA C-80A 4.5M is available now for immediate purchase. Ideal for various electrical applications requiring reliable circuit protection.
