4 Way F Type Splitter | 5-2400MHz Frequency Range | RFI Shielding 120dB | Compact Design by Cabac
This 4 way F type splitter operates within a 5-2400MHz frequency range, making it ideal for distributing signals in homes and offices. Built for reliable performance, it features a compact design for easy installation and space-saving.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: 4 Way F Type Splitter | 5-2400MHz Frequency Range | Compact Design | Easy Installation by FOXAP
Brand: Cabac
SKU: 05FSPLT4
Alternatively Known As: 4 Way F Type Splitter, Foxtel Approved F Splitter, 4 Port F Connector Splitter
Technical Specifications
- Frequency response: 5-2300 MHz
- RFI shielding: 120dB
- Impedance: 75 Ohm
- Power pass: 12V DC, 500mA on all ports
- Housing: Nickel plated zinc die-cast
- Connector type: High precision machine threaded F-ports
- Dimensions (H x L x W): 25mm x 80mm x 80mm
- Weight: 0.2 kg
Key Features
- Foxtel Approved
- Nickel plated zinc die-cast housing
- Tongue groove housing design provides high RFI shielding for 120dB
- Frequency response of 5-2300 MHz
- High precision machine threaded F-ports
- Power pass 12V DC, 500mA on all ports
- Impedance: 75 Ohm
Professional Installation Requirements
- Professional installation by a qualified technician is recommended to ensure optimal signal distribution and compliance with safety standards.
Applications
- Allows 4 TVs to share the same antenna
- Suitable for special channels and return channels
- Audio/Video signal distribution in residential and commercial settings
Standards & Compliance
- Complies with AS/NZS 60950 – Safety of IT and Communication Equipment
Environmental Benefits
- Durable nickel plated zinc die-cast housing reduces the need for frequent replacements, minimizing electronic waste.
Warranty Information
1 year warranty against manufacturing defects.
Available Now
The FOXAP 4 Way 5-2400MHz F Type Splitter by Cabac is available now for immediate purchase. Ideal for residential and commercial audio/video signal distribution applications.
