5 Wire Splitter 2 Way | 4 Satellite 1 Terrestrial | 5-2400 MHz | Metal Housing by Matchmaster
5 wire splitter with 4 satellite and 1 terrestrial input—ideal for homes and commercial buildings. Built for efficient signal distribution, with durable metal housing and wide frequency range.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: TERRA 5 Wire Splitter 2 Way 4 Satellite 1 Terrestrial
Brand: Matchmaster
SKU: 21MM-SD504
Alternatively Known As: 5 Wire Splitter, Satellite Splitter, Terrestrial Splitter
Technical Specifications
- Frequency Range: SAT IF 950-2400 MHz, Terr. TV 5-862 MHz
- Through Loss: SAT IF 4dB, Terr. TV 4dB
- Tap Loss: SAT IF 4dB, Terr. TV 4dB
- SAT Inputs Decoupling: SAT IF 30dB, Terr. TV 30dB
- DC Pass Through: H Lines 2 A Max (1 A Max Through One Line), Terr. TV Lines 0.1 A Max
- Return Loss: >10dB
- Operating Temperature Range: -20° ÷ +50°C
- Dimensions (H x L x W): 30mm x 135mm x 126mm
- Weight: 0.44 kg
Key Features
- Foxtel approved (F30812)
- 2 way splitter of 4 satellite + 1 terrestrial TV signals
- Low losses with DC pass through satellite TV trunk lines
- Switchable DC pass to tap H outputs
- Accepts central pin diameter 1.2 mm maximum
- Used with 5 Wire products only
Professional Installation Requirements
- Professional installation is recommended for optimal performance and compliance with local regulations.
Applications
- Residential: Homes, apartments, and entertainment systems
- Commercial: Offices, hotels, and public venues
Environmental Benefits
- Designed for efficient signal distribution, reducing the need for multiple devices.
Warranty Information
1 year warranty against manufacturing defects.
Available Now
The TERRA 5 Wire Splitter 2 Way 4 Satellite 1 Terrestrial is available now for immediate purchase. Ideal for residential and commercial applications requiring efficient signal distribution.
