5-Wire Splitter 2-Way 5-2400MHz TDT Variant Low-Loss Matchmaster
5 wire splitter with 5-2400 MHz range and low insertion loss—ideal for satellite and terrestrial signal distribution.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Frequency range: SAT IF 950-2400 MHz, Terr. TV 5-862 MHz.
- Through loss: SAT IF 4 dB, Terr. TV 4 dB.
- Tap loss: SAT IF 4 dB, Terr. TV 4 dB.
- SAT inputs decoupling: SAT IF 30 dB, Terr. TV 30 dB.
- DC pass through: V line 0.5 A max, H line 1 A max, Terr. TV line 0.1 A max.
- Return loss: > 10 dB.
- Operating temperature range: -20° ÷ +50°C.
- Dimensions (H x L x W): 30mm x 126mm x 135mm
- Weight: 0.44 kg
Key Features
- Designed for splitting 5 input lines (4 satellite and 1 terrestrial TV) into 2 paths.
- Foxtel approved.
- Meets shielding requirements of class A according to standard EN50083-2.
- Intended for indoor use only.
- Consists of 5 highly isolated splitters for every input line.
Professional Installation Requirements
- Professional installation is recommended for optimal performance and compliance with local regulations.
Applications
- Residential: Home entertainment systems
- Commercial: Offices, hotels, and public venues requiring satellite and terrestrial TV distribution
Environmental Benefits
- Designed for efficient signal distribution, reducing the need for multiple devices.
Warranty Information
1 year warranty against manufacturing defects.
Available Now
The TERRA 5 Wire Splitter 2 Way 4 Satellite 1 Terrestrial is available now for immediate purchase. Ideal for residential and commercial applications requiring reliable TV signal distribution.
