Alternatively Known As: Astral EVO LED Downlight, 2CCT LED Downlight, Modular Low-Glare Downlight, Recessed LED Ceiling Light
- Power: 9 W
- Lumen Output: 1001 lm at 3000K / 927 lm at 4000K
- Colour Temperature: 3000K / 4000K selectable
- Efficacy: 118 lm/W at 3000K / 110 lm/W at 4000K
- Dimming: Phase-cut trailing-edge, 10–100%; DALI optional
- Beam Angle: 60°
- Colour Rendering Index: CRI >90
- Glare Rating: UGR <19
- Flicker: Flicker-free driver
- Cut-out Size: 90 mm
- Driver: Remote driver with 0.6 m flex and plug
- Input Voltage: 220–240 V AC, 50/60 Hz
- Power Factor: >0.9
- Electrical Classification: Class II
- Ingress Protection: IP54 front / IP20 rear
- Insulation Rating: IC-4
- Operating Temperature: -20°C to 40°C
- Body Material: Plastic
- Diffuser Material: Polycarbonate lens
- Reflector: Interchangeable matt silver reflector, accessory code EV-REF-SIL
- Projected Lifespan: 50,000 hours at Ta 25°C, L80B50
- Dimensions (H x L x W): 42mm x 115mm x 115mm
- Weight: 0.25 kg
- Selectable warm white or neutral white output via 3000K/4000K CCT switch
- Modular silver reflector for a refined, low-glare appearance
- Deep-recessed optical design with UGR <19
- Remote driver supports flexible installation and maintenance access
- IC-4 rated for covered and abutted insulation installations where permitted
- Phase-cut trailing-edge dimmable from 10–100%
- High colour rendering with CRI above 90
- Suitable for shallow ceiling spaces with a compact recessed profile
- Installation and mains electrical connection must be completed by a licensed electrician in accordance with the manufacturer's installation instructions and applicable Australian electrical requirements. Confirm dimmer compatibility before installation.
- Residential bedrooms and living areas
- Bathrooms and laundries
- Dining areas and kitchens
- Hotel rooms and hospitality interiors
- Retail spaces, showrooms and display lighting
- Offices, meeting rooms and commercial interiors
- Accent and feature lighting
- AS/NZS 60598.1 for general luminaire safety requirements
- AS/NZS 60598.2.2 for recessed luminaires and downlights
- Haneco states that its LED lighting products comply with applicable Australian and New Zealand electrical safety standards, including the AS/NZS 60598 series. ([haneco.com.au](https://haneco.com.au/support/faqs/?utm_source=openai))
- High efficacy of up to 118 lm/W reduces electricity use compared with less efficient lighting technologies
- 50,000-hour projected LED lifespan can reduce replacement frequency and associated waste
- IC-4 construction allows insulation coverage where permitted, helping preserve the ceiling's thermal envelope
- Selectable CCT and interchangeable reflector support adaptable installations without replacing the complete luminaire
5-year manufacturer warranty for the AST9W-EV model, subject to Haneco's warranty terms. Haneco's general policy provides replacement for manufacturing defects and requires installation by a licensed electrician. ([haneco.com.au](https://haneco.com.au/import/downloads/AST9W-EV_DATASHEET_AST9W-EV.pdf?utm_source=openai))
Available through Haneco and authorised Australian electrical distributors, subject to distributor stock levels.
