Alternatively Known As: Haneco AURORA110-SQ, Aurora Square Commercial Downlight, Square LED Recessed Downlight
- Rated Power: 10 W
- Light Output: 991 lm at 3000K, 1039 lm at 4000K, 1011 lm at 5700K
- Colour Temperature: 3000K / 4000K / 5700K selectable
- Dimming: DALI dimmable model; phase-cut trailing-edge version also available
- Ingress Protection: IP54 from below
- Cutout: 90 x 90 mm
- Input Voltage: 220-240 V AC, 50/60 Hz
- Power Factor: >0.9
- Colour Rendering Index: CRI >85
- Beam Angle: 90°
- Driver: Remote driver
- Electrical Classification: Class II, double insulated
- Connection: Flex and plug
- Expected Lifetime: >50,000 hours at Ta 25°C, L70
- Operating Temperature: -20°C to 45°C
- Housing: Aluminium
- Diffuser: Opal polycarbonate
- Insulation Clearance: Do not cover with building insulation
- Dimensions (H x L x W): 51mm x 110mm x 110mm
- Weight: 0.26 kg
- Square recessed commercial downlight design
- Three selectable colour temperatures from one fitting
- IP54 protection from below for suitable bathroom, laundry and wet-room applications
- DALI dimming option for lighting-control systems
- Remote driver supplied separately from the luminaire
- Flicker-free operation
- High-efficiency LED performance up to 111 lm/W
- Recessed opal diffuser for reduced glare
- KASTA-compatible control platform
- Metal spring clip mounting
- Suitable for residential and commercial applications
- Installation must be performed by an authorised and licensed electrician in accordance with the manufacturer's instructions and AS/NZS 3000. The fitting must not be covered by insulation, and the DALI driver and control wiring must be installed by a suitably qualified electrical contractor. ([manuals.plus](https://manuals.plus/m/009453317de68a3b328852142807e1ccd31ce3e903f0349ec4bbb7e51061a205))
- Bathrooms and ensuites
- Kitchens and laundries
- Retail spaces and showrooms
- Offices and boardrooms
- Hotel common areas
- Medical and education facilities
- Entrances, function areas and commercial interiors
- Applicable recessed-luminaire standard: AS/NZS 60598.2.2
- Electrical installation should comply with AS/NZS 3000 Wiring Rules. ([energysafe.vic.gov.au](https://www.energysafe.vic.gov.au/industry-guidance/electrical/appliances-equipment-and-manufacurers/equipment-classes?utm_source=openai))
- LED technology provides high luminous efficacy, reducing energy consumption compared with less efficient light sources
- Expected life of more than 50,000 hours can reduce replacement frequency and associated waste
- Aluminium housing and polycarbonate components may be recyclable subject to local recycling facilities
- Selectable colour temperature reduces the need to stock multiple fixed-CCT fittings
- Class II double-insulated construction reduces reliance on protective-earth wiring for the luminaire
5-year warranty is specified for the Aurora Square range. Haneco's general Australian product warranty provides direct replacement for manufacturing defects, typically for 3-5 years depending on the product. ([haneco.com.au](https://haneco.com.au/import/downloads/AURORA%20SQUARE_Haneco_AURORA%20SQ_ProductFlyeR.pdf?utm_source=openai))
Available through Haneco and authorised Australian electrical wholesalers or local electricians. ([haneco.com.au](https://haneco.com.au/contact/?utm_source=openai))
