4MP Bi-Spectrum Fire & Smoke Detection Camera | 256 x 192 Resolution | IR 15M Range | by Dicker Data
The 4MP Bi-Spectrum Fire & Smoke Detection Camera offers advanced thermal imaging with a 256 x 192 resolution and an impressive IR range of 15 meters. Perfect for fire detection in commercial and industrial settings, this camera features smoke detection algorithms and video content analysis for enhanced safety monitoring. Built for reliability, it ensures early detection to prevent large-scale damage.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: 4MP Bi-Spectrum Fire & Smoke Detection Camera | 256 x 192 Resolution | IR 15M Range | by Dicker Data
Brand: Dicker Data
SKU: DS-2TD1228T-3-QA
Alternatively Known As: Thermal Fire Detection Camera, Bi-Spectrum Smoke Detector Camera, HIKVISION Thermal Surveillance Camera
Technical Specifications
- Thermal Sensor Resolution: 256 × 192
- Pixel Size: 12 μm
- Detector Type: VOx UFPA
- NETD: < 40 mK at 25°C, F1.0
- Temperature Measurement Range: -20°C to 550°C (-4°F to 1,022°F)
- Temperature Accuracy: ± 2°C or ± 2%
- Video Content Analysis: Vehicle and human classification
- Image Processing: Linear, histogram, self-adaptive thermal AGC mode, DDE, 3D DNR
- IR Range: 15 meters
- Special Algorithms: Smoke detection, sun-reflection filter, forklift alarm filter
- Dimensions (H x L x W): 100mm x 150mm x 120mm
- Weight: 1.5 kg
Key Features
- 256 × 192 thermal resolution with 12 μm VOx UFPA sensor
- NETD < 40 mK at 25°C, F1.0 for high thermal sensitivity
- Video content analysis with vehicle and human classification
- Temperature exception alarm range from -20°C to 550°C with ±2°C or ±2% accuracy
- Supports smoke detection algorithm
- Image processing technologies including linear, histogram, self-adaptive thermal AGC mode, DDE, and 3D DNR
- Sun-reflection filter and forklift alarm filter algorithms for enhanced detection accuracy
- IR illumination up to 15 meters
- High quality detector with 10 years guarantee
Professional Installation Requirements
- Installation by a qualified security systems technician or electrician is recommended to ensure proper setup and compliance with safety standards.
Applications
- Fire detection and prevention in commercial and industrial facilities
- Smoke detection in warehouses and storage areas
- Surveillance in environments requiring thermal and visual monitoring
- Safety monitoring in manufacturing plants and logistics centers
Standards & Compliance
- Complies with AS/NZS 4801 – Occupational Health & Safety Management Systems
Environmental Benefits
- Early fire and smoke detection helps prevent large-scale environmental damage.
- Energy-efficient thermal imaging reduces power consumption compared to traditional fire detection systems.
Warranty Information
3 years warranty provided by the manufacturer covering defects and performance issues.
Available Now
The HIKVISION HEAT PRO 2TD1228T-3 camera is available for immediate purchase, ideal for fire and smoke detection in commercial and industrial safety applications.
