Contactor 40A 4NC 230V 50Hz High Electric Endurance Grey Hager
Hager Contactor 40A 4NC 230V 50Hz High Electric Endurance Grey. Ideal for motor control and industrial switching.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Type of contacts: 4NC
- Number of contacts: 4
- Cross-section flexible conductor: 1.5 - 16 mm²
- Cross-section rigid conductor: 1.5 - 25 mm²
- Rated current: 40 A
- Number of modules: 3
- Frequency: 50 - 50 Hz
- Rated impulse withstand voltage Uimp: 4000 V
- Rated insulation voltage Ui: 440 V
- Command voltage AC: 230 - 230 V
- Command voltage DC: 0 - 0 V
- Operating temperature: -10 - 50 °C
- Storage/transport temperature: -40 - 80 °C
- Number of mechanical operations: 100000
- Electric endurance in number of cycles: 30000
- Total power loss under IN: 12.80 W
- Inrush power absorbed: 62.50 VA
- Height: 85 mm
- Width: 54 mm
- Depth: 60 mm
- Number of NO contacts: 0
- Number of NC contacts: 4
- With switch for manual switch: No
- Dimensions (H x L x W): 85mm x 60mm x 54mm
- Weight: 0.4 kg
Key Features
- Reliable switching for electrical circuits
- Supports flexible and rigid conductor connections
- Durable with high electric endurance
Professional Installation Requirements
- Professional installation by a qualified electrician is recommended for optimal safety.
Applications
- Residential and commercial electrical installations
- Switching circuits requiring high current capability
Standards & Compliance
- Complies with relevant Australian electrical standards.
Environmental Benefits
- Efficient power loss management
- Long-lasting mechanical operations reduce waste
Warranty Information
5 years warranty against manufacturing defects.
Available Now
Available for immediate purchase. Ideal for residential and commercial circuit switching needs.
