Copper Crimp Lug 300sqmm M8 Stud Narrow Palm Tinned Wattmaster
Wattmaster narrow-palm narrow palm copper crimp lug for 300sqmm cable, M8 stud. Electro-tinned, to AS NZS 4325.1.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Material: 99.9% Electro grade copper
- Finish: Electro tinned for corrosion resistance
- Stud Size: M8
- Cable Size: 300mm²
- Operating Temperature: -55°C to +155°C
- Compliance: AS/NZS 4325.1:1995 (cl7) for sizes >10mm²
- Dimensions (H x L x W): 10mm x 120mm x 40mm
- Weight: 0.15 kg
Key Features
- Non-insulated electro grade copper crimp lugs
- Narrow palm design for modular circuit breakers or narrow connections
- Electro tinned finish for corrosion resistance
- Includes inspection port for easy verification
- High conductivity with 99.9% copper content
Professional Installation Requirements
- Installation should be performed by a qualified electrician to ensure proper crimping and secure connections.
Applications
- Electrical wiring connections for circuit breakers
- Industrial and commercial electrical installations
- Stranded to fine-stranded copper cable terminations
Standards & Compliance
- Complies with AS/NZS 4325.1:1995 for electrical copper lugs
Environmental Benefits
- Electro tinned finish enhances durability reducing replacement frequency
- High conductivity reduces energy loss in electrical systems
Warranty Information
Warranty against manufacturing defects as per Wattmaster standard policy.
Available Now
The Wattmaster Crimp Lug Copper Narrow Palm 300mm² M8 Stud is available for immediate purchase, ideal for electrical wiring and circuit breaker connections.
