Cylindrical Supercapacitor 1.0F 5.5V | Low ESR 30Ω | Through Hole Terminals | Eaton
Cylindrical supercapacitor with 1.0F capacitance and 5.5V maximum voltage—ideal for energy storage in commercial electronics. Built for reliable backup power and pulse applications, featuring low ESR of 30Ω and RoHS compliance.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Cylindrical Supercapacitor 1.0F 5.5V | Low ESR 30Ω | Through Hole Terminals | Eaton
Brand: Eaton
SKU: KR-5R5C105-R
Alternatively Known As: Supercapacitor Coin Cell, KR Series Supercapacitor, 1F 5.5V Capacitor, Cylindrical Supercapacitor
Technical Specifications
- Capacitance: 1.0 F
- Maximum Voltage: 5.5 V
- Equivalent Series Resistance (ESR): 30 Ω
- Energy: 15.1 J
- Power: 0.1 W
- Peak Current (1 sec): 0.1 A
- Operating Temperature Range: -25 °C to +70 °C
- Terminals: Through hole
- Shape: Cylindrical coin cell
- Capacitance End of Life Rating: 70%
- ESR End of Life Rating: 400%
- Grade: Commercial
- Dimensions (H x L x W): 7.1mm x 7.1mm x 7.1mm
- Weight: 0.0091 kg
Key Features
- Capacitance of 1.0 Farad
- Maximum voltage rating of 5.5 V
- Cylindrical coin cell shape with through hole terminals
- Low equivalent series resistance (ESR) of 30 Ω
- Operating temperature range from -25 °C to +70 °C
- Commercial grade with RoHS compliance
Professional Installation Requirements
- Installation by qualified electronics technician recommended to ensure proper handling and soldering of through hole terminals.
Applications
- Energy storage in electronic circuits
- Backup power for memory and real-time clocks
- Power smoothing and pulse power applications
- Commercial electronic devices requiring high capacitance
Standards & Compliance
- AS/NZS 3820 – Essential Safety Requirements for Electrical Equipment
Environmental Benefits
- RoHS compliant ensuring reduced hazardous substances
- Long lifecycle reduces electronic waste
- Energy-efficient storage for low power applications
Warranty Information
Standard Eaton commercial product warranty applies; please refer to Eaton's warranty policy for details.
Available Now
The Eaton KR 1.0F 5.5V Cylindrical Coin Cell Supercapacitor is available now for immediate purchase. Ideal for commercial electronic applications requiring reliable energy storage.
