D200 Door Station Recess Mount Audio Monitoring Silver iCentral
iCentral D200 door station features recess mounting, audio monitoring and a silver finish. Ideal for 200 Series intercom systems.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Alternatively Known As: System One D200 Audio Door Station, iCentral D200AS, M200 Series Audio Door Station
Technical Specifications
- Model: D200AS
- Finish: Silver
- Station Type: Audio door station without camera
- Mounting: Recess mount
- System Compatibility: System One 200 Series masters, room stations and accessories
- Audio Functions: Audio monitoring and hands-free door communication
- Controls and Indicators: Illuminated door chime button, backlit buttons and microphone activity indication
- Microphone: Sensitive electret microphone
- Fascia Dimensions: 265 mm wide x 130 mm high
- Recess Dimensions: 205 mm wide x 95 mm high x 30 mm deep
- Origin: Designed and made in Australia
- Dimensions (H x L x W): 130mm x 265mm x 30mm
- Weight: 0.8 kg
Key Features
- Recess-mounted door station for System One 200 Series intercom systems
- Silver fascia finish
- Audio monitoring capability
- Hands-free communication from connected room stations
- Compatible with System One 200 Series masters, room stations and accessories
- Illuminated door chime press button
- Backlit operating buttons
- Built-in sensitive electret microphone
- Supports door call, paging and selective room calling functions
Professional Installation Requirements
- Installation requires recessed wall mounting and connection to the System One intercom wiring. Installation should be completed by a suitably qualified low-voltage or security-system technician in accordance with the manufacturer’s instructions and applicable electrical wiring requirements.
Applications
- Residential entrance intercom systems
- Home audio door communication
- System One 200 Series intercom installations
- Replacement of compatible D200 silver audio door stations
- Multi-room residential communication systems
Standards & Compliance
- AS/NZS 62368.1:2018 — applicable safety standard for audio, video, information and communication technology equipment
- AS/NZS 3000:2018 — applicable wiring requirements where the intercom installation interfaces with electrical installation wiring
Environmental Benefits
- Low-power intercom operation compared with continuously powered video door stations
- Durable metal-faced construction can extend service life and reduce replacement waste
- Repair or replacement of the door station within an existing System One installation can avoid replacing the complete intercom system
Warranty Information
iCentral intercom systems are covered by a one-year warranty against defective components from the date of purchase, subject to the manufacturer’s warranty conditions.
Available Now
Available through iCentral, Ness Corporation and authorised Australian security and intercom distributors.
