DALI/DSI Digital Dimming PSU | Presence Detection | Supports 10 Drivers | Pre-wired RJ11 | @EA of 1 | by CP Electronics

BRAND: CP Electronics
SKU: EBMPIR-PSU-DDR
$149.30 List price: $186.10
+ −
30 Days Return Delivery Options
The DALI/DSI Digital Dimming PSU with presence detection is perfect for commercial lighting control, supporting up to 10 drivers or ballasts. Its pre-wired RJ11 connection simplifies installation, while the PIR sensor ensures energy savings by automatically switching off lights in unoccupied areas. Ideal for office buildings, this dimming power supply enhances energy efficiency and integrates seamlessly with DALI/DSI systems.

Product Name/Title: DALI/DSI Digital Dimming PSU | Presence Detection | Supports 10 Drivers | Pre-wired RJ11 | @EA of 1 | by CP Electronics

Brand: CP Electronics

SKU: EBMPIR-PSU-DDR

Alternatively Known As: DALI Digital Dimming PSU, Presence Detector Relay, PIR Lighting Control Module, Digital Dimming Power Supply Unit

Technical Specifications
  • Relay rating: 6A (standard PSU), 2A (slim-line PSU)
  • Mounting height: up to 2.8 meters
  • Connection: Pre-wired with RJ11 plug
  • Control: Presence/absence detection via PIR sensor
  • Compatibility: DALI/DSI digital dimming ballasts
  • Programmable via UHS5 or UNLCDHS handsets
  • Supports switching and dimming with lux level lensing
  • No background monitoring or acoustic sensor
  • No connection cable included
  • Dimensions (H x L x W): 30mm x 120mm x 80mm
  • Weight: 0.3 kg
Key Features
  • Small and unobtrusive design
  • Pre-wired with RJ11 plug for easy connection
  • Supports up to 10 drivers/ballasts
  • Presence and absence detection with PIR sensor
  • Compatible with DALI/DSI digital dimming ballasts
  • Adjustable timeout period for automatic switching off
  • Programmable via UHS5 or UNLCDHS handsets
  • Multiple versions available including standard and slim-line power supplies
  • Two channel flexibility with scene setting and recall
  • Supports maintained illuminance and daylight harvesting
Professional Installation Requirements
  • Installation by a qualified electrician is required to ensure compliance with electrical standards and safe integration with lighting systems.
Applications
  • Lighting control in commercial and office buildings
  • Presence and absence detection for energy saving
  • Integration with DALI/DSI digital dimming ballasts
  • Suitable for mounting in or on luminaires up to 2.8m height
Standards & Compliance
  • AS/NZS 3000 – Wiring Rules (Electrical Installation)
  • AS/NZS 3112 – Plugs and Socket-Outlets (Type I Plug)
Environmental Benefits
  • Reduces energy consumption by automatically switching off lights when areas are unoccupied
  • Supports daylight harvesting to optimize natural light use
  • Enhances energy efficiency in lighting systems
Warranty Information

Standard manufacturer warranty applies, typically 2 years.

Available Now

The CP Electronics DALI/DSI Digital Dimming Standard PSU Presence/Absence Detection Relay is available for immediate purchase, ideal for commercial lighting control and energy management applications.
