DALI Dimming Miniature Microwave Presence Detector | IP40 Rated | 360° Detection | by CP Electronics
The DALI Dimming Miniature Microwave Presence Detector is designed for automatic lighting control in commercial spaces. With a 360° detection angle and an 8m diameter range, it ensures energy efficiency by automatically switching off lights when areas are unoccupied. Ideal for integration with DALI/DSI dimming ballasts, this detector is perfect for ceiling tile or solid ceiling mounting, making it a versatile choice for modern lighting solutions.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: DALI Dimming Miniature Microwave Presence Detector | IP40 Rated | 360° Detection | by CP Electronics
Brand: CP Electronics
SKU: MWS5-DD-SA-C
Alternatively Known As: Microwave Presence Detector, DALI Dimming Sensor, Ceiling Mounted Occupancy Sensor, IP40 Microwave Sensor, Miniature Presence Detector
Technical Specifications
- Detection technology: High frequency microwave sensor
- Detection angle: 360° horizontal
- Detection range: 8 m diameter on floor
- Voltage: 230 V AC, 50 Hz
- Max switching power: 1380 W
- Standby current: 3.77 mA
- IP rating: IP40
- Impact rating: IK05
- Operating temperature: -10 to 80 °C
- Material: Halogen free thermoplastic
- Mounting: Surface mounted in ceiling tiles or solid ceilings
- Programmable via UHS5 or UNLCDHS handsets
- Compatible with DALI/DSI digital dimming ballasts and 1-10V analogue dimming ballasts
- Dimensions (H x L x W): 40mm x 20mm x 40mm
- Weight: 0.1 kg
Key Features
- Miniature microwave presence detector for automatic lighting control
- Compatible with incandescent, fluorescent, and compact fluorescent lighting
- Direct dim variant controls DALI or DSI digital dimming ballasts
- Presence and absence detection with lux level sensing
- Programmable via UHS5 or UNLCDHS handsets
- Adjustable time-out period for switching off lights
- Surface mounted with supplied clips
- IP40 rated with IK05 impact protection
- Nominal voltage 230V AC, 50Hz frequency
- 360° detection angle with 8m diameter reach on floor
- Standby consumption approximately 3.77 mA
- Halogen free thermoplastic material with matt white finish
Professional Installation Requirements
- Installation should be performed by a qualified electrician to ensure compliance with electrical standards and proper integration with lighting control systems.
Applications
- Lighting control in commercial and office buildings
- Automatic presence detection for energy saving
- Integration with DALI/DSI digital dimming ballasts
- Suitable for ceiling tile or solid ceiling mounting
Standards & Compliance
- AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Reduces energy consumption by automatically switching off lights when areas are unoccupied
- Supports dimming to optimize lighting levels and reduce power usage
- Helps lower carbon footprint through efficient lighting management
Warranty Information
Standard manufacturer warranty applies; typically 2 years against manufacturing defects.
Available Now
The CP Electronics DALI Dimming Miniature IP40 Ceiling Flush Mounted Microwave Presence/Absence Detector with PSU is available for immediate purchase, ideal for commercial and office lighting control applications.
