Flexible Metal Conduit Anaconda ACW 20mm 1m Blue Wattmaster
Wattmaster 20mm flexible galvanised steel conduit (1m length) features interlocked flexible construction. Ideal for AS NZS 3000 compliant electrical installations.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Conduit size: 1/2 inch (20mm)
- IP rating: IP67 with approved connectors
- Temperature rating: -40ºC to +80ºC
- Approved for use in hazardous locations per NEC Articles 501, 502, 503
- Approved as equipment grounding conductor for sizes 1/2" through 1-1/4" under specified conditions
- Suitable for direct burial and concrete encasement
- Dimensions (H x L x W): 20mm x 1000mm x 20mm
- Weight: 0.3 kg
Key Features
- IP67 rated when installed with approved connectors
- Suitable for hazardous locations per NEC Articles 501, 502, and 503
- Approved as equipment grounding conductor for specific sizes and conditions
- Manufactured in a full range of trade sizes from 1/2" through 3"
- Rated for temperature range -40ºC to +80ºC
- Approved for direct burial and concrete encasement
Professional Installation Requirements
- Installation should be performed by a licensed electrician familiar with hazardous location wiring and conduit installation standards.
Applications
- Electrical wiring protection in hazardous locations
- Industrial and commercial electrical installations
- Use in exposed and concealed conduit runs
- Direct burial and concrete encasement applications
Standards & Compliance
- Complies with AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Durable construction reduces need for frequent replacements
- Supports safe electrical installations minimizing environmental hazards
Warranty Information
Standard manufacturer warranty applies. Please refer to Wattmaster warranty policy for details.
Available Now
The Wattmaster Flexible Metal Conduit 1/2" Anaconda ACW Computer Blue Intrinsically Safe is available for immediate purchase, ideal for industrial and hazardous location electrical installations.
