Trade Discount 25%
Flexible Metal Conduit Anaconda LDEF 16mm 30m Black Wattmaster
Wattmaster 16mm flexible galvanised steel conduit (30m length) features interlocked flexible construction. Ideal for AS NZS 3000 compliant electrical installations.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Diameter: 16mm
- Length: 30m
- Core: Galvanized steel
- Cover: Gray thermoplastic PVC
- Temperature rating: -20°C to +70°C (up to +80°C intermittent)
- IP Rating: IP67 with correctly installed fittings
- Conforms to IEC 61386 standard
- No copper ground wire
- Dimensions (H x L x W): 16mm x 30000mm x 16mm
- Weight: 1.2 kg
Key Features
- Provides flexible dust and liquid tight protection of cables
- Extra flexible general construction grade liquid-tight wiring conduit with galvanized steel core
- Durable, sunlight resistant gray thermoplastic PVC cover
- Smooth appearing cover with convenient markings in feet
- IP67 rating with correctly installed fittings
- Temperature range from -20°C to +70°C (up to +80°C intermittent)
- Uses standard liquid-tight fittings for easy installation
Professional Installation Requirements
- Installation should be performed by a qualified electrician to ensure proper fitting and maintain IP67 rating.
Applications
- Cable protection in harsh industrial and outdoor environments
- Flexible wiring conduit for electrical installations requiring dust and liquid tight protection
- Suitable for exposed applications needing sunlight resistance and durability
Standards & Compliance
- Complies with AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Durable construction reduces need for frequent replacements, minimizing waste
- Sunlight resistant materials extend product life in outdoor applications
Warranty Information
Warranty terms as per Wattmaster standard product warranty policy.
Available Now
The Wattmaster Flexible Conduit Anaconda LDEF Liquidtight 16mm Diameter 30m Length Black is available for immediate purchase, ideal for industrial, commercial, and outdoor electrical wiring protection.
FAQ
Q: What is the operating temperature range of this conduit?
A: The conduit is rated for temperatures from -20°C to +70°C, with intermittent exposure up to +80°C.
Q: Is this conduit suitable for outdoor installations?
A: Yes, it is designed for harsh industrial and outdoor environments and features a sunlight-resistant thermoplastic PVC cover with IP67 protection when correctly installed.
Connect conduit runs using a flexible conduit fitting nylon straight for secure terminations in electrical installations.
Support conduit along mounting surfaces with a flexible conduit clip with plug designed for conduit retention.
Install a flexible metal conduit fitting where threaded equipment connections are required.
