Flexible Metal Conduit Anaconda LDEF 20mm 30m Orange Wattmaster
Wattmaster 20mm flexible galvanised steel conduit (30m length) features interlocked flexible construction. Ideal for AS NZS 3000 compliant electrical installations.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Diameter: 20mm
- Length: 30m
- Core: Galvanized steel
- Cover: Gray thermoplastic PVC, sunlight resistant
- IP Rating: IP67 with correctly installed fittings
- Temperature Range: -20°C to +70°C (up to +80°C intermittent)
- Conforms to IEC 61386
- No copper ground wire
- Dimensions (H x L x W): 20mm x 30000mm x 20mm
- Weight: 1.2 kg
Key Features
- Provides flexible dust and liquid tight protection of cables
- Extra flexible general construction grade liquid-tight wiring conduit with galvanized steel core
- Durable, sunlight resistant, gray thermoplastic PVC cover
- Smooth appearing cover with convenient markings in feet
- IP67 rating with correctly installed fittings
- Temperature range from -20°C to +70°C (up to +80°C intermittent)
Professional Installation Requirements
- Installation should be performed by a qualified electrician to ensure proper fitting and compliance with electrical safety standards.
Applications
- Cable protection in harsh industrial and outdoor environments
- Flexible wiring conduit for electrical installations requiring dust and liquid tight protection
- Suitable for exposed applications needing sunlight resistance and durability
Standards & Compliance
- Complies with AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Durable construction reduces the need for frequent replacements, minimizing waste
- Sunlight resistant materials extend product life in outdoor applications
Warranty Information
Standard manufacturer warranty applies; please refer to Wattmaster for specific warranty details.
Available Now
The Wattmaster Flexible Conduit Anaconda LDEF Liquidtight 20mm Diameter 30m Orange is available for immediate purchase, ideal for industrial, commercial, and outdoor electrical wiring protection.
FAQ
Q: What are the main specifications of this conduit?
A: This conduit has a 20mm diameter, 30m length, galvanized steel core, thermoplastic PVC cover, and an IP67 rating when used with correctly installed fittings.
Q: What applications is this conduit suitable for?
A: It is designed for cable protection in harsh industrial and outdoor environments, including electrical installations requiring dust and liquid tight protection and sunlight resistance.
Complete the installation with a flexible conduit fitting nylon straight NC32 M32 flame retardant fitting for secure conduit termination points.
Support conduit runs using a flexible conduit clip 20-25mm to maintain neat and secure cable routing.
Where conduit enters equipment, a corrugated cable gland 32mm can assist with protected cable entry management.
