High Bay PIR Presence/Absence Detector | IP40 Rated | 40m Detection Range | Programmable Functionality | @Each of 1 | by CP Electronics
The High Bay PIR Presence/Absence Detector is designed for efficient lighting control in industrial and commercial spaces. With a groundbreaking detection range of up to 40m at a 15m mounting height and IP40 rating, it ensures reliable performance. Fully programmable via UHS5 or UNLCDHS handsets, this sensor is perfect for energy-saving applications, reducing unnecessary lighting usage based on presence detection.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: High Bay PIR Presence/Absence Detector | IP40 Rated | 40m Detection Range | Programmable Functionality | @Each of 1 | by CP Electronics
Brand: CP Electronics
SKU: EBDHS-DH-PRM
Alternatively Known As: High Bay PIR Detector, PIR Presence Detector Head, High Bay Motion Sensor, Flush Mounted PIR Sensor
Technical Specifications
- Detection range: up to 40m at 15m mounting height
- Maximum mounting height: 20m
- IP rating: IP40
- Lens technology: Unique high sensitivity lens
- Programmable via UHS5 or UNLCDHS handsets
- Switching with lux level sensing
- Absence detection functionality
- No background monitoring or acoustic sensor
- Connection cable length: 0 mm (no cable supplied)
- Dimensions (H x L x W): 40mm x 60mm x 60mm
- Weight: 0.2 kg
Key Features
- Groundbreaking detection range up to 40m at a 15m mounting height
- Maximum mounting height up to 20m depending on operating parameters
- Unique lens technology providing high sensitivity within detection range
- Adjustable masking shields to tailor detection zones
- Verify feature reduces false triggering by requiring detection from multiple internal sensors
- Fully programmable functionality using UHS5 or UNLCDHS handsets
- Switching with lux level sensing and absence detection functionality
Professional Installation Requirements
- Installation should be performed by a qualified electrician to ensure compliance with electrical standards and optimal sensor performance.
Applications
- High bay lighting control in warehouses
- Industrial and commercial high ceiling areas
- Presence and absence detection for energy saving
- Lighting control in demanding spaces with increased mounting heights
Standards & Compliance
- AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Reduces energy consumption by controlling lighting based on presence and absence detection
- Helps lower carbon footprint through efficient lighting management
Warranty Information
Standard manufacturer warranty applies, typically 2 years.
Available Now
The CP Electronics PRM Switching IP40 High Bay Flush Mounted PIR Presence/Absence Detector Head is available for immediate purchase, ideal for warehouse and industrial high bay lighting control applications.
