In-Line Duct Fan 310mm | 4 Pole 1Ph | Compact Design | IP55 Rated by Fantech
In-line duct fan with 310mm diameter and 4 pole motor—ideal for ducted ventilation systems. Built for residential and commercial use, with compact design and IP55 rating for robust performance.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Short cased in-line duct fan 310mm 4 pole 1Ph
Brand: Fantech
SKU: SCE314
Alternatively Known As: Inline Duct Fan, Axial Duct Fan, Ventilation Fan
Performance Curve
Technical Specifications
- Electricity supply: 230V single-phase or 415V three-phase, 50Hz
- Motor type: Squirrel cage induction motor
- IP Rating: IP55
- Bearings: Sealed-for-life, ball
- Air flow tests to ISO 5801: 2004
- Noise tests to BS848, Part 2, 1985
- Dimensions (H x L x W): 310mm x 500mm x 310mm
- Weight: 5 kg
Key Features
- Compact, short case design for easy installation.
- Light-weight but robust construction with galvanised steel casing.
- Capable of operating in ambient temperatures from -20°C to +70°C.
- Speed-controllable using electronic or auto-transformer controllers.
- Integral thermal protection supplied as standard.
Professional Installation Requirements
- Professional installation by a qualified technician is recommended for optimal performance.
Applications
- Ducted ventilation systems in residential and commercial buildings
- Air circulation in industrial environments
Standards & Compliance
- Complies with relevant Australian standards for safety and performance.
Environmental Benefits
- Energy-efficient design reduces power consumption.
Warranty Information
1 year warranty against manufacturing defects.
Available Now
The Fantech Short Cased In-Line Duct Fan 310mm 4 Pole 1Ph is available now for immediate purchase. Ideal for ducted ventilation systems in various applications.
