Industrial Ethernet Cable M12 to RJ45 Cat6A 0.6m SICK
Built for industrial Ethernet connections in zones with oils and lubricants, this SICK cable has male RJ45, 8-pin, straight connectors on both ends. The 0.6m shielded CAT6A cable supports data rates up to 10 Gbit/s, with a halogen-free PUR jacket and conductor insulation rated flame retardant to UL 1581 and IEC 60332-1-2. It's built to AS/NZS 60950 safety standards for IT and communication equipment. Full technical specifications and installation notes are listed below.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Connection type head A: Male connector, RJ45, 8-pin, straight
- Connection type head B: Male connector, RJ45, 8-pin, straight
- Connector material: TPU
- Cable length: 0.6 m
- Cable type: 8-wire, PUR, halogen-free
- Cable diameter: 6.4 mm
- Conductor cross section: 0.14 mm²
- Shielding: Shielded
- Nominal voltage: 125 V AC
- Test voltage: 1,000 V AC
- Reference voltage: 60 V DC
- Signal type: Ethernet, Gigabit Ethernet
- Transmission characteristics: CAT6A
- Data transmission rate: ≤ 10 Gbit/s
- Operating temperature: Stationary -40°C to +80°C, Head -25°C to +85°C
- Enclosure rating: IP20
- Contamination rating: 3
- Insulation resistance: > 100 mΩ
- Thermal resistance: Flame retardant acc. to UL 1581 and IEC 60332-1-2
- Dimensions (H x L x W): 6mm x 600mm x 6mm
- Weight: 0.1 kg
Key Features
- Male RJ45 8-pin straight connectors on both ends
- Shielded CAT6A cable supporting data rates up to 10 Gbit/s
- Cable jacket and conductor insulation are halogen-free PUR
- Flame retardant according to UL 1581 and IEC 60332-1-2 standards
- Operating temperature range: -40°C to +80°C (stationary), -25°C to +85°C (head)
- IP20 enclosure rating suitable for protected environments
- Contamination rating 3 for industrial use
Professional Installation Requirements
- Installation by qualified personnel is recommended to ensure proper connection and compliance with safety standards.
Applications
- Industrial Ethernet connections in zones with oils and lubricants
- Data transmission requiring Gigabit Ethernet speeds
- Environments requiring flame retardant and halogen-free cabling
Standards & Compliance
- Complies with AS/NZS 60950 – Safety of IT and Communication Equipment
Environmental Benefits
- Halogen-free cable materials reduce toxic emissions in case of fire
- Flame retardant properties enhance safety and reduce fire hazards
Warranty Information
Standard manufacturer warranty applies; please refer to SICK's official warranty policy.
Available Now
The SICK YMRJA8-C60EG1MRJA8 Ethernet CAT6A Shielded Cable is available for immediate purchase, ideal for industrial Ethernet applications requiring robust and flame retardant cabling.
FAQ
Q: What connectors does this cable use?
A: It has male RJ45, 8-pin, straight connectors on both ends, with a halogen-free PUR jacket and conductor insulation.
Q: What data rate does this cable support?
A: It supports transmission rates up to 10 Gbit/s over shielded CAT6A conductors, and it's backed by SCHNAP's 30-day returns policy for added purchasing confidence.
For a shorter run in the same shielded RJ45-to-RJ45 Cat6A range, the industrial ethernet cable is also available at 0.3m.
An angled M12 to RJ45 Cat6A ethernet cable offers a mixed connector configuration for M12-terminated equipment.
