ISO Enclosed Isolator 3P 100A IP65 Aluminium Grey Blue Handle NHP
The NHP ISO Enclosed Isolator 3P 100A IP65 provides reliable isolation for industrial machinery and commercial electrical distribution systems. Rated at 100 A with a 690 V insulation voltage and IP65 protection, it features an aluminium enclosure and padlock locking capability. Its 3-pole configuration and 10–70 mm² connectable conductor cross section support electrical installation requirements. Review the technical specifications and installation requirements below before selecting this isolator.
Sign in
Please login to continue to your account.
- Rated Permanent Current: 100 A
- Number of Poles: 3
- Frequency: 50/60 Hz
- Rated Operation Current: 100 A at AC-23A 690 V
- Rated Short Time Withstand Current: 5 kA
- Rated Insulation Voltage: 690 V
- Rated Operating Voltage: 690 V
- Conditioned Rated Short Circuit Current: 20 kA
- Number of Auxiliary Contacts: 0 NC, 0 NO
- Degree of Protection: IP65, NEMA 4X
- Connectable Conductor Cross Section: 10-70 mm²
- Dimensions (H x L x W): 298mm x 124mm x 200mm
- Weight: 0.55 kg
- IP65 rated for protection against dust and water ingress.
- Padlock locking feature for enhanced safety.
- Professional installation by a qualified electrician is recommended for optimal safety.
- Industrial: Machinery and equipment isolation
- Commercial: Electrical distribution systems
- General: Safety isolation in various electrical installations
- Complies with relevant Australian standards for electrical safety.
- Durable design reduces the need for frequent replacements.
Standard warranty applies.
The Socomec ISO Enclosed Isolator is available now for immediate purchase. Ideal for industrial and commercial electrical applications.
Q: What is the current rating of the NHP ISO Enclosed Isolator?
A: The isolator has a rated permanent current of 100 A and a rated operation current of 100 A at AC-23A 690 V.
Q: What protection and safety features does this isolator provide?
A: It has IP65 protection, a NEMA 4X rating and a padlock locking feature for enhanced safety.
For installations requiring additional circuit protection and isolation, consider a 3-pole fuse combination switch rated at 125A.
A DIN rail isolating switch provides another option for controlling electrical circuits within distribution boards.
For lower-current circuit isolation requirements, a 63A isolating switch is another option to consider.
Understanding switch amp ratings helps electricians assess current requirements when selecting electrical isolation equipment.
