MCB 2P 10kA C-100A | 415V Rated | Compact Design by Hager
Miniature circuit breaker with 2-pole design and 100A current rating—ideal for residential and commercial electrical installations. Built for safety and efficiency, with 10kA breaking capacity and compact dimensions.
Sign in
Please login to continue to your account.
Product Name/Title: MCB 2P 10kA C-100A 3M
Brand: Hager
SKU: HMF290T
Alternatively Known As: Miniature Circuit Breaker, MCB, Circuit Protection Device
- Type of pole: 2P
- Rated operational voltage: 415V
- Rated insulation voltage: 500V
- Rated impulse withstand voltage: 6000V
- Frequency: 50 - 60 Hz
- Rated current: 100A
- Rated short-circuit breaking capacity: 10kA
- Nominal tightening torque: 3.5 - 5.0 Nm
- Electric endurance: 4000 cycles
- Mechanical operations: 20000 cycles
- Cross-section for massive conductors: 1 - 70 mm²
- Cross-section for flexible conductors: 1 - 50 mm²
- Dimensions (H x L x W): 90mm x 70mm x 53mm
- Weight: 0.5 kg
- 2-pole design for efficient circuit protection.
- Rated current of 100A with a breaking capacity of 10kA.
- Screw terminal connections for secure installation.
- Suitable for AC voltage supply of 415V.
- Professional installation by a qualified electrician is recommended for optimal safety.
- Residential: Homes, apartments, and electrical installations
- Commercial: Offices, retail spaces, and industrial applications
- Complies with AS/NZS 60898 for safety and performance standards.
- RoHS and REACH compliant, contributing to reduced environmental impact.
2 years warranty against manufacturing defects.
The Hager MCB 2P 10kA C-100A 3M is available now for immediate purchase. Ideal for residential and commercial electrical installations.
