MCB 2P 10kA C-80A | 415V AC | Screw Terminal by Hager
Miniature circuit breaker with 80A rated current and 10kA breaking capacity—ideal for residential, commercial, and industrial applications. Built for reliable circuit protection, with easy screw terminal installation.
Sign in
Please login to continue to your account.
Product Name/Title: MCB 2P 10kA C-80A 3M
Brand: Hager
SKU: HMF280T
Alternatively Known As: Miniature Circuit Breaker, MCB, Circuit Protection Device
- Type of pole: 2P
- Curve: C
- Rated insulation voltage: 500V
- Rated impulse withstand voltage: 6000V
- Frequency: 50 - 60 Hz
- Nominal tightening torque: 3.5 - 5.0 Nm
- Electric current: Rated current 80A
- Endurance: 4000 electrical cycles, 20000 mechanical operations
- Cross-section for massive conductors: 1 - 70 mm²
- Cross-section for flexible conductors: 1 - 50 mm²
- Degree of pollution: 3
- Dimensions (H x L x W): 90mm x 70mm x 53mm
- Weight: 0.5 kg
- Rated current of 80A with a breaking capacity of 10kA.
- Designed for AC voltage supply with a rated operational voltage of 415V.
- Screw terminal connections for easy installation.
- Professional installation by a qualified electrician is recommended for optimal safety.
- Residential: Homes, apartments, and small buildings
- Commercial: Offices and retail spaces
- Industrial: Factories and manufacturing facilities
- Complies with AS/NZS 60898 for safety and performance standards.
- RoHS and REACH compliant, contributing to reduced environmental impact.
2 years warranty against manufacturing defects.
The Hager MCB 2P 10kA C-80A 3M is available now for immediate purchase. Ideal for circuit protection in various applications.
