MCB 2P 15kA C-80A | 415V AC | Compact 3M by Hager
Miniature circuit breaker with 2 poles and 15kA breaking capacity—ideal for residential, commercial, and industrial applications. Built for safety and reliability, with 80A rated current and compact 3M design.
Sign in
Please login to continue to your account.
Product Name/Title: MCB 2P 15kA C-80A 3M
Brand: Hager
SKU: HMC280T
Alternatively Known As: Miniature Circuit Breaker, MCB, Circuit Protection Device
- Type of pole: 2P
- Curve: C
- Rated insulation voltage: 500V
- Rated impulse withstand voltage: 6000V
- Frequency: 50 - 60 Hz
- Cross-section of input and output with screws for massive conductors: 1 - 70 mm²
- Cross-section of input and output with screws for flexible conductors: 1 - 50 mm²
- Degree of pollution: 3
- Dimensions (H x L x W): 90mm x 70mm x 53mm
- Weight: 0.5 kg
- Rated operational voltage: 415V AC
- Rated current: 80A
- Rated short-circuit breaking capacity: 15kA
- Nominal tightening torque: 3.5 - 5.0 Nm
- Electric endurance: 4000 cycles
- Professional installation by a qualified electrician is recommended for optimal safety.
- Residential: Homes, apartments, and small buildings
- Commercial: Offices and retail spaces
- Industrial: Factories and manufacturing facilities
- Complies with AS/NZS 60898 for safety and performance standards.
- RoHS and REACH compliant, contributing to reduced environmental impact.
2 years warranty against manufacturing defects.
The Hager MCB 2P 15kA C-80A 3M is available now for immediate purchase. Ideal for circuit protection in various applications.
