MCB 3P 6kA C-16A | 3-Pole Design | IP20 Rated | Hager

BRAND: :hager
SKU: MSN316
$68.90 List price: $88.10
+
Miniature circuit breaker with 16A current and 6kA breaking capacity—ideal for residential, commercial, and light industrial applications. Built for safety, with a 3-pole design and IP20 rating for indoor use.

Product Name/Title: MCB 3P 6kA C-16A 3M

Brand: Hager

SKU: MSN316

Alternatively Known As: Miniature Circuit Breaker, MCB, Circuit Protection Device

Technical Specifications
  • Rated operational voltage: 415V
  • Rated insulation voltage: 500V
  • Rated impulse withstand voltage: 4000V
  • Frequency: 50 - 60 Hz
  • Operating temperature: -25 to 70 °C
  • Total power loss under IN: 6.99W
  • Type of connection: Screw terminal
  • Dimensions (H x L x W): 83mm x 70mm x 52.5mm
  • Weight: 0.5 kg
Key Features
  • Rated current of 16A with a breaking capacity of 6kA.
  • 3-pole design suitable for three-phase systems.
  • IP20 ingress protection for indoor use.
Professional Installation Requirements
  • Professional installation by a qualified electrician is recommended for optimal safety.
Applications
  • Residential: Homes, apartments, and small buildings
  • Commercial: Offices and retail spaces
  • Industrial: Light industrial applications requiring circuit protection
Standards & Compliance
  • Complies with AS/NZS 60898 for circuit breakers.
Environmental Benefits
  • Designed to improve electrical safety and reduce fire hazards.
Warranty Information

2 years warranty against manufacturing defects.

Available Now

The Hager MCB 3P 6kA C-16A 3M is available now for immediate purchase. Ideal for residential, commercial, and industrial applications.

MSN316 (MSN316, 179 Kb) [Download]

reach_declaration_MSN3164.pdf (reach_declaration_MSN3164.pdf, 103 Kb) [Download]

RoHS-declaration-MSN3164.pdf (RoHS-declaration-MSN3164.pdf, 33 Kb) [Download]

(MSN1_2_3XX_MCBS_6KA_C.pdf, 110 Kb) [Download]

(DECLARATION_24_3601_10_24.pdf, 537 Kb) [Download]

(DECLARATION_24_3593_10_24.pdf, 542 Kb) [Download]
